Inspection 4-2 ISSUE4
1. Preparation
Prepare the following equipment for inspection.
2. Inspection Procedure
Connect the Electrosurgical Analyzer to the UES-40. (Refer to the Electrosurgical Analyzer
instruction manual for details.)
Refer to the following table to check output values:
The above listed measurement points can cover all output specifications, because there are
no difference other than the amplitude of waveform in each output mode.
Name Model Specifications Remarks
Electrosurgical Analyzer 454A – DNI NEVADA INC.
Table 4-1 Setting and output of each mode
Output mode Load resistance [¾] UES-40 output setting [W] Standard [W]
Monopolar Spray 200 60 48-72
Monopolar Coag. 1 300 60 48-72
Monopolar Coag. 2 300 60 48-72
Monopolar Blend 300 125 100-150
Monopolar Cut 300 150 120-180
Bipolar Soft1 100 45 36-54
Saline Blend 100 160 128-192
