OMB EM 1000 HE DIG PLUS COMPACT - Amplifier Module and Filters

FM TRANSMITTER
TR EM 1000 HE DIG PLUS COMPACT
Technical Manual 1v2 November 2019 71
COMPADA 1v1 BOARD
DESCRIPTION REFERENCE
QUANTITY
Capacitor SMD 1206 ±10% 50V 100nF
C1, C2, C3, C4, C5, C6, C9, C11, C12
9
Capacitor SMD 1206 1uF X7R>16V <± 10%
C7, C8, C10
3
Capacitor SMD 1206 ±10% 16V 10uF
C13
1
Diode Schottky SOD323F 0.5A
PMEG3005EJ
D1
1
Diode Schottky SOT-23 BAT 54C DOBLE
COMM-K BAT54C
D2
1
Diode Zener SOT-23 BZX84C3V3
D3
1
Strip 5 pins male-male pitch 2.54 THD
J1
1
Connector 3W 5.08 straight PCB 10ª
J4, J7
2
IDC10 PCB Straight male IDC10
J6, J8
2
Connector SMD 6 PCB straight Micro-
match 7-188275-6
J9
1
BJT NPN BC817 SMD SOT-23 BC817
Q1, Q2
2
Resistor SMD 1206 0,25W ±1% 10K
R1,R8,R9,R11,R16,R20
6
Resistor SMD 1206 5% 110R
R2, R10
2
Resistor SMD 1206 5% 1K
R3,R4,R6,R7,R25,R26,R27
7
Resistor SMD 1206 0,25W ±1% 3K3
R5
1
Resistor SMD 1206 1% 2K2
R12,R17,R22
3
Resistor SMD 1206 1% 18K
R13,R19
2
Resistor SMD 1206 1% 4K7
R14
1
Resistor SMD 1206 1% 12K
R18,R23
2
Resistor SMD 1206 1% 1K5
R21
1
Resistor SMD 1206 1% 180R
R24
1
Resistor SMD 1206 1% 22K
R28
1
Micro-controller, 8-Pin SOIC 150mil
PIC12F615-I/SN
U1
1
Dual Rail-to-Rail Op Amp SMD SOIC-8
MC33202
U2
1
3-Terminal Voltage Regulator SMD DPAK-3
78M05
U3
1
