OMB EM 1000 HE DIG PLUS COMPACT - Driver Module

FMTRANSMITTER
TREM1000HEDIGPLUSCOMPACT

TechnicalManual1v2November2019  72
3.810WDRIVERBOARD



Figure:10Wdriverboard

ThisamplifierboardreceivesthesignalfromtheFMSYNTHETIZERmodule.TheRFsignalthat
comes from this module is filtered and amplified by a MOSFET Q1 MRF6V2010NBR5. The
amplifier circuit has a variable power supply that ranges between 30Vdc and 50Vdc, after
passingthroughtheLM317regulator,30Vddsareobtained.

The output power of this DRIVER is variable, so the output power depends on the Byas
voltagethatisappliedtothetransistor.ThisvoltageofByascomesfromthetensionofthe
ALCloop.ThisvoltageisgeneratedbytheCONTROLCARDbymeansofaPWMsignalthatwill
bedeterminedbytheoperatinglogicandoperatingstatusoftheequipment.

Thisboardalsoworksasaninterfaceforthesignalsthataregeneratedinthefinalstageand
output filter, reaching the FWD, REF and temperature signals, which are sent to the MAIN
BOARDwheretheyareprocessedandsenttotheCONTROLBOARD.







