OMB EM 1000 HE DIG PLUS COMPACT - Page 82

FM TRANSMITTER
TR EM 1000 HE DIG PLUS COMPACT
Technical Manual 1v2 November 2019 77
1200W FM Amplifier Module
DESCRIPTION REFERENCE QUANTITY
SMD 0805 ±10% 50V 1nF Capacitor
C1, C21, C28, C36
4
SMD 0805 ±10% 50V 10
0nF Capacitor
C2, C23, C29, C34,
C37
5
SMD 1206 ±10% 50V 1uF Capacitor
C3, C22, C35
3
SMD 1210 ±10% 200V 1nF Capacitor
C6, C7, C17, C18
4
SMD 1210 ±10% 200V 470pF Capacitor
C8, C10, C13, C16
4
SMD 1008 ±5% 50V 56nH Inductance
C9
1
SMD 0805 ±10% 50V 47pF Capacitor
C11
1
SMD 0805 ±5% 50V 10pF Capacitor
C12
1
SMD 1210 ±10% 500V 15pF Capacitor
C14
1
SMD 1210 ±10% 500V 3.9pF Capacitor
C15
1
SMD ≥50V D8mm 100uF electrolytic Capacitor
C24, C33
2
SMD 1206 ±10% 100V 1nF Capacitor
C25, C30
2
SMD 1206 ±10% 100V 10nF Capacitor
C26, C31
2
SMD SOT23 5.1V BZX84C5V1 Zener Diode
D2
1
Binocular Ferrite FT8
FIL1
1
Air core ind 1812 56nH
L1
1
NPN SMD SOT23 PMBT2222A Transistor
Q2
1
SMD 2512 1W 220R Resistance
R1, R4
2
SMD 1206 ±10% 50V 47pF Capacitor
R2
1
SMD 0805 0.125W ±5% 22R Resistance
R5, R6
2
SMD 0805 0.125W ±5% 2K2 Resistance
R8
1
SMD 0805 0.125W ±5% 12K Resistance
R9
1
Single turn 1K 3/8’’ 1kΩ Potentiometer
R10
1
SMD 0805 0.125W ±5% 5K1 Resistance
R11
1
SMD 0805 0.125W ±5% 2K2 Resistance
R12
1
SMD 0805 0.125W ±5% 1K1 Resistance
R13, R14
2
SMD 0805 0.125W ±5% 390 Resistance
R15
1
SMD 0805 0.125W ±5% 4K7 Resistance
R16
1
SMD 0805 0.125W ±5% 910 Resistance
R17
1
Input transformer
TR1
1
Ferrite for input transformer
TR1’
1
Transformer primary copper wire
7xD0.086mm Teflon 3 turn
TR1’’
1
Transformer secondary silvered copper wire
D1.3mm 1 turn
TR1’’’
1
Output transformer
TR2
1
Hex. Separ. H-H 10mm Brass-Nickel
H1, H2
2
