Omega CNI16 User Manual

61
J
K
T
E
R
S
B
C
N
L
RTD
RTD
Table 4.1 Input Properties
TC Input Type Range Accuracy*
Iron-Constantan -210 to 760°C 0.4°C
-346 to 1400°F 0.7°F
-270 to -160°C 1.0°C
CHROMEGA
®
- -160 to 1372°C 0.4°C
ALOMEGA
®
-454 to -256°F 1.8°F
-256 to 2502°F 0.7°F
-270 to -190°C 1.0°C
Copper-Constantan -190 to 400°C 0.4°C
-454 to -310°F 1.8°F
-310 to 752°F 0.7°F
-270 to -220°C 1.0°C
CHROMEGA- -220 to 1000°C 0.4°C
Constantan -454 to -364°F 1.8°F
-364 to 1832°F 0.7°F
-50 to 40°C 1.0°C
Pt/13%Rh-Pt 40 to 1788°C 0.5°C
-58 to 104°F 1.8°F
104 to 3250°F 0.9°F
-50 to 100°C 1.0°C
Pt/10%Rh-Pt 100 to 1768°C 0.5°C
-58 to 212°F 1.8°F
212 to 3214°F 0.9°F
200 to 640°C 1.0°C
30%Rh-Pt/ 640 to 1820°C 0.5°C
6%Rh-Pt 212 to 1184°F 1.8°F
1184 to 3308°F 0.9°F
5%Re-W/ 0 to 2354°C 0.4°C
26%Re-W 32 to 4253°F 0.7°F
-250 to -100°C 1.0°C
Nicrosil-Nisil -100 to 1300°C 0.4°C
-418 to -148°F 1.8°F
-148 to 2372°F 0.7°F
J -200 to 900°C 0.4°C
DIN -328 to 1652°F 0.7°F
Pt, 0.00385, 100 Ω, 200 to 900°C 0.4°C
500 Ω, 1000 Ω -328 to 1652°F 0.7°F
Pt, 0.00392, 100 Ω, -200 to 850°C 0.4°C
500 Ω, 1000 Ω -328 to 1562°F 0.7°F
PROCESS
Voltage 0 to 100 mV, 0 to 1 V, 0.03% rdg
0 to 10 Vdc 0.03% rdg
PROCESS Current 0 to 20 mA, 4 to 20 mA 0.03% rdg
