Omega RDXL4SD - Page 7

Power Current Normal operation ( w/o SD card save
data and LCD Backlight is OFF) :
Approx. DC 8.5 mA.
When SD card save the data but and
LCD Backlight is OFF) :
Approx. DC 30 mA.
*
A
If LCD backlight on, the power
consumption will increase approx.
14 mA.
Weight 489 g/1.08 LB.
Dimension 177 x 68 x 45 mm
(7.0 x 2.7x 1.9 inch)
Accessories *Instruction Manual
Included
Optional
Accessories
* USB cable, USB-01.
* RS232 cable, UPCB-02.
* Data Acquisition software,
SW-U801-WIN.
* AC to DC 9V adapter.
* Hard carrying case, CA-06.
* Soft carrying case, CA-05A.
2-2 Electrical Specifications (23± 5°C)

PT 100 ohm
Resolution Range Accuracy
0.1  -199.9 to 850.0°C  ± ( 0.4 % + 1°C)
0.1  -327.0 to 999.9°F  ± ( 0.4 % + 1.8°F)
1  1000 to 1562°F  ± ( 0.4 % + 2°F)
*
Pt 100 ohm probe TP-101 is the optional accessory.
4
*4 Type K Thermocouples
*6-AA Alkaline Batteries
*2 GB-SD (2 GB SD Card)
