Omicron Bode 100 Quick Start Guide

5.2 Bode 100 specifications
Table 5-2: Bode 100 specifications:
Characteristic Rating
OUTPUT
Voltage range -30 dBm...13 dBm
7 mVrms...1 Vrms at 50 Ω load
14 mVrms...2 Vrms at high impedance load
Frequency range 1 Hz...50 MHz
Wave form sinusoidal
Source impedance 50 Ω
Connector BNC
INPUT CH 1, INPUT CH 2
AC measurement range 100 mVrms full scale with 0 dB input attenuation
10 Vrms full scale with 40 dB input attenuation
Frequency range 1 Hz...50 MHz
Input impedance Selectable via software:
50 Ω or
1 MΩ ±2% || 40...55 pF (AC-coupled)
Connectors BNC
Input attenuators Selectable via software:
0 dB, 10 dB, 20 dB, 30 dB, 40 dB
Receiver bandwidth Selectable via software:
1 Hz, 3 Hz, 10 Hz, 30 Hz, 100 Hz, 300 Hz, 1 kHz,
3 kHz , 5 kHz
Dynamic Range > 100 dB (10 Hz receiver bandwidth)
Gain Error < 0.1 dB (calibrated)
Phase Error < 0.5° (calibrated)
PC interface
Universal serial bus USB 2.0 or higher
Connector USB type B socket
DC Power requirements
Supply voltage range +9 ... 24 V
Minimum DC supply power 10 W
Connector Coaxial power socket (2.5 mm / 5.5mm)
We strongly recommend to use the power supply delivered with Bode 100.
Technical data
OMICRON Lab
13
