Omicron Bode 100 Quick Start Guide

4 Bode 100 and accessories
4.1 Delivered items
Bode 100
multi functional test set
Bode Analyzer Suite on DVD
Wide-range AC power supply
including mains input plugs for
different national standards
Test objects
(Quartz filter and IF filter) on
PCB
USB Cable
4 pc. BNC 50 Ω cables with 500
mm length (m-m)
BNC adapters (straight, T, Short,
Load 50 Ω)
Bode 100 Quick Start Guide
The delivered items may vary a bit from the look shown above. Please refer to the packing
list received with the Bode 100 for further information
Bode 100 Quick Start Guide
10
OMICRON Lab

Omicron Bode 100 Specifications

General

Brand	Omicron
Model	Bode 100
Category	Measuring Instruments
Language	English
