5 Technical data
In this section you can find the most important technical data for the Bode 100 Revision 2. Technical
data can change without notice.
You can download a detailed technical data sheet for Bode 100 from the OMICRON Lab website
www.omicron-lab.com → Bode 100 → Technical Data .
NOTICE
Risk of permanent damage of the device.
Exceeding the absolute maximum ratings might result in equipment damage.
► Do not exceed the absolute maximum ratings listed below.
5.1 Absolute maximum ratings
Table 5-1: Absolute maximum ratings
Characteristic Absolute Maximum Rating
DC Power Input
DC supply voltage +28 V
Max. DC supply reverse voltage -28 V
INPUT CH 1, INPUT CH 2 connectors (high Z input impedance selected )
Maximum DC input signal 50 V
Maximum AC input signal 1 Hz...1 MHz: 50 Vrms
1 MHz...2 MHz: 30 Vrms
2 MHz...5 MHz: 15 Vrms
5 MHz...10 MHz: 10 Vrms
10 MHz ... 50 MHz: 7 Vrms
INPUT CH 1, INPUT CH 2 connectors (50 Ω input impedance selected)
Maximum input power 1 W
Maximum input voltage 7 Vrms
OUTPUT connector
Maximum reverse power 0.5 W
Maximum reverse voltage 3.5 Vrms
Bode 100 Quick Start Guide
12
OMICRON Lab
