Omicron Bode 100 Quick Start Guide

Bode 100 provides the following three connectors at the rear panel:
• DC power input:
input for DC voltages from 9 V to 24 V (5.5 mm coaxial plug with 2.5 mm pin)
• USB: data interface (USB type B port)
• : Ground connector for external ground connection (4 mm banana-socket)
Figure 6-2: Bode 100 rear view
NOTICE
Risk of permanent damage of the device.
Exceeding the absolute maximum ratings might result in equipment damage.
► The AC-coupled inputs represent a high impedance for DC signal. Before using passive probes,
check out 7.5 Using external probes on page 21.
Bode 100 Quick Start Guide
16
OMICRON Lab
