Omicron CPC 100 Getting Started

CPC Getting Started
18 OMICRON
7. Turn on the CPC at its POWER switch at the left-hand side.
The green status light "0" lights up, showing that the current/voltage source is not active.
8.Set up your test in the CPC software, and, where applicable, determine whether you want to
perform an automatic or a manual test.
9. Once all test cards are prepared and the parameters set, make sure the key lock is in "unlocked"
position (horizontal). Release the Emergency Stop button.
10.Start the test by pressing the I/O (test start/stop) push-button on the CPC front panel.
Note:
• A test can only be started in the Test Card View and with all preconditions met.
• If voltages
≥ 500 V are to be applied, after pressing the I/O (test start/stop) push-button for the first
time a warning message appears on the screen. Only after the I/O (test start/stop) push-button is
pressed a second time, the voltage is applied to the CPC output.
• An error message (313) appears if no PE connection can be detected on the power supply.
11.If a potentially hazardous voltage and/or current level is fed by the CPC outputs, the red
status light "I" starts flashing.
WARNING
Death or severe injury caused by high voltage or current possible
If none or both lights on the front panel are lit, the CPC is either not supplied by mains or
it is defective.
► If the CPC is defective, do not use it.
► Contact OMICRON support.
WARNING
Death or severe injury caused by high voltage or current possible
This is a safety-relevant message. If the reason for this message is that the PE is not
connected, this can cause injury or possibly death of the operating staff.
► Make sure that both PE and grounding terminal are connected.

Omicron CPC 100 Specifications

General

Brand	Omicron
Model	CPC 100
Category	Test Equipment
Language	English
