OMNI-624/OMNI-624EU Installation and Setup Guide
6-6
INSTALLER MODE 1 (INSTALLER KEYPAD PROGRAMMING)
Enters the installer into keypad programming mode, which has 4 submodes (see below). To exit, simply
press the [
STAY
] key and return to the prior panel status. To change between these submodes, press
[
✱
] + [BYPASS] + Submode No.
The LCD display for Installer Mode 1, Submodes 1–3 is:
Q:xx MX Edit L:yy
Data dddd DDD
where: Qxx = question number (00–99)
MX = programming submode (1–3)
Edit = shows you are in edit mode, meaning that changes to values can be made
Lyy = location within the programming question
Data = cue to indicate next four digits as data
dddd = 4 digits of the data entries (press [#] to display the next 4 digits for those questions
having more than 4 digit entries
DDD = Mode description (1-System, 2-Zn/Cde, 3-RF Prg,)
For submode 4, the display is:
Q:xx DESC Z:zz
16-character descriptor
where: Qxx = question number
DESC = shows you are in descriptor mode (Submode 4)
Zzz = zone number for which descriptor is being programmed
2
nd
line = up to 16-character descriptor
Submode 1: System (Questions 1–68)
Use this mode to program system options.
Submode 2: Zone programming, zone enables, report codes (Questions 1–53)
Use this mode to program zone information/attributes and all CS report codes, and to assign the
first wireless zone and/or first zone-doubling zone.
Submode 3: Wireless Zone/Keyfob Programming (Questions 1–32)
Use this mode to configure wireless transmitters and to enter transmitter/keyfob serial numbers.
Submode 4: Descriptor Programming (Questions 1–26)
Use this mode to enter alpha descriptors for each zone. (LCD keypads only.)
NOTE:
An option in the Compass Downloader Software inhibits keypad programming. If you select it,
then the keypad will emit 4 short beeps after you attempt to enter this mode.
INSTALLER MODE 2 (PROGRAM REVIEW)
This mode is the same as Mode 1, except no changes to programming data can be made. It is intended
as a way to review the settings of programming Submodes 1–4 without altering their values.
INSTALLER MODE 3 (WALK TEST with Reduced RF Gain)
Once the points are placed in their desired locations, open or short circuit each point. The keypad will
beep and annunciate with activation of each zone or point while in this mode. Pressing 1 toggles the
external bell on and off.
