Section 6. System Programming
6-51
L2:
Should always be “1,” unless you want to swap the order of zone numbering for the transmitter’s
loops 1 and 2, in which case enter “9.” For example, if you are using a 2-loop transmitter such as the
ZR510 or 5816 and only want to use the magnetic reed switch (loop 2) you would enter 9 so that loop 2
would be treated as loop 1.
L3
–
L9:
Enter the transmitter’s 7-digit serial number
Q 01 WIRELESS ZONE 1 Q 09 WIRELESS ZONE 9 Q 17 WIRELESS ZONE 17
Q 02 WIRELESS ZONE 2 Q 10 WIRELESS ZONE 10 Q 18 WIRELESS ZONE 18
Q 03 WIRELESS ZONE 3 Q 11 WIRELESS ZONE 11 Q 19 WIRELESS ZONE 19
Q 04 WIRELESS ZONE 4 Q 12 WIRELESS ZONE 12 Q 20 WIRELESS ZONE 20
Q 05 WIRELESS ZONE 5 Q 13 WIRELESS ZONE 13 Q 21 WIRELESS ZONE 21
Q 06 WIRELESS ZONE 6 Q 14 WIRELESS ZONE 14 Q 22 WIRELESS ZONE 22
Q 07 WIRELESS ZONE 7 Q 15 WIRELESS ZONE 15 Q 23 WIRELESS ZONE 23
Q 08 WIRELESS ZONE 8 Q 16 WIRELESS ZONE 16 Q 24 WIRELESS ZONE 24
QUESTION 25–32 KEYFOB CONFIGURATION/SERIAL NUMBER
L1 L2 L3 L4 L5 L6 L7 L8 L9
No. of buttons enable RF –––––––––––––Keyfob 7-digit serial number –––––––––––––––––
These questions assign the number of buttons used by each keyfob and store the keyfob’s serial
numbers. See Installer Submode 1, Questions 49–64 to assign the keyfob button functions. Use the
separate Programming Form to enter the actual values for each keyfob.
L1:
Number of buttons used on the transmitter (1–4).
L2:
Should always be “1.”
L3–L9:
Enter the keyfob’s 7-digit serial number.
Q 25 KEYFOB 1 CONFIGURATION/SERIAL NUMBER
Q 26 KEYFOB 2 CONFIGURATION/SERIAL NUMBER
Q 27 KEYFOB 3 CONFIGURATION/SERIAL NUMBER
Q 28 KEYFOB 4 CONFIGURATION/SERIAL NUMBER
Q 29 KEYFOB 5 CONFIGURATION/SERIAL NUMBER
Q 30 KEYFOB 6 CONFIGURATION/SERIAL NUMBER
Q 31 KEYFOB 7 CONFIGURATION/SERIAL NUMBER
Q 32 KEYFOB 8 CONFIGURATION/SERIAL NUMBER
Programming Submode 4: DESCRIPTOR PROGRAMMING
Press [
✱
] [BYPASS] while in Installer Mode 1, then press [4] to enter Descriptor Programming
submode.
To create a descriptor:
1. Press [
✱
] then the Question number representing the zone number desired.
