OMNI-624/OMNI-624EU Installation and Setup Guide
6-52
2. Press the INSTANT key to move the cursor to the desired location within that Question.
3. Press one of the character display keys (see table below) to display the character set.
4. When the desired character appears, press INSTANT. The character is accepted and the cursor
moves to the next location. To move to a previous location to change a character, if needed, press
CODE.
5. When the descriptor is complete, accept the entry by pressing [
✱
] then the next Question number.
Refer to the following chart when entering descriptors:
Key Function
INSTANT Accepts displayed character and moves cursor forward one
position.
CODE Moves cursor backward one position.
[7] Displays next character in character set.
[9] Displays previous character in character set.
[#] [7] Automatically scrolls character set display forward.
[#] [9] Automatically scrolls character set display backward.
[8] Stops auto scrolling.
[0] Inserts a blank character.
QUESTIONS 01–24 ZONE DESCRIPTORS FOR ZONES 01–24
L1 L2 L3 L4 L5 L6 L7 L8 L9 L10 L11 L12 L13 L14 L15 L16
These questions allow you to enter up to 16-digit descriptors for each zone. Each digit corresponds to a
single descriptor character. Use the separate Programming Form to enter the actual descriptors for
each zone.
Descriptor For: Descriptor For: Descriptor For: Descriptor For:
Q 01 ZONE 1 Q 07 ZONE 7 Q 13 ZONE 13 Q 19 ZONE 19
Q 02 ZONE 2 Q 08 ZONE 8 Q 14 ZONE 14 Q 20 ZONE 20
Q 03 ZONE 3 Q 09 ZONE 9 Q 15 ZONE 15 Q 21 ZONE 21
Q 04 ZONE 4 Q 10 ZONE 10 Q 16 ZONE 16 Q 22 ZONE 22
Q 05 ZONE 5 Q 11 ZONE 11 Q 17 ZONE 17 Q 23 ZONE 23
Q 06 ZONE 6 Q 12 ZONE 12 Q 18 ZONE 18 Q 24 ZONE 24
QUESTIONS 25–26 PARTITION DESCRIPTORS
L1 L2 L3 L4 L5 L6 L7 L8 L9 L10 L11 L12 L13 L14 L15 L16
This question allows you to enter up to 16 digits for partitions 1 and 2. Each digit
corresponds to a single character in the descriptor.
Q 25 DESCRIPTOR FOR PARTITION 1 Q 26 DESCRIPTOR FOR PARTITION 2
To Next Page
