6.6. Input Terminal Selections
Input Terminal SelectionsInput Terminal Selections
Input Terminal Selections
Input terminals 1 to 9, A, and B are open collector inputs. Pulse inputting is possible for Terminals
A and B.
For the content of an input signal, by allocating the functions that you want to operate to [CA-01]
to [CA-11], you will be able to operate the functions with a corresponding input terminal operation.
You can switch a contact for an input signal with the Contacts a/b selection functions of [CA-21] to
[CA-31].
When a function is selected for many targets, the targets will be set to 00 [without allocation],
excluding the finally set function selection.
