Inverter Specifications
12
400V Class Specifications
*1. The rated input currents shown in the table are the values when the rated current is output. The values vary depending on impedance on the power supply
(wiring, breaker, input reactor option, etc.) Select peripheral devices that have enough margin with reference to these values, which are different from ones
shown on the product nameplate.
*2. The power supply equipment capacities shown in the table are the values when 220V rated current is output. The values vary depending on impedance on
the power supply (wiring, breaker, input reactor option, etc.)
*3. The setting of rated values for carrier frequencies [bb101]/[bb201] are internally limited in accordance with the description. Also, it is recommended to set
values equivalent to or above (maximum output frequency for driving ×10) Hz for the setting of carrier frequencies [bb101]/[bb201]. Also, in the case of
induction motor (IM) control, for items other than those subject to V/f control, it is recommended to set carrier frequency at 2kHz or more. In the case of
synchronous motor (SM)/permanent magnet motor (PMM) control, it is recommended to set carrier frequency at 8kHz or more.
*4. The value of the sensor-less vector control applied to the ND rating in the Standard motor. Torque characteristics may vary depending on the control
method and the motor used.
*5. Based on self declaration.
3G3RX2-
A4007 A4015 A4022 A4037 A4055 A4075 A4110 A4150 A4185 A4220 A4300 A4370 A4450 A4550 B4750 B4900 B411K B413K
Applicable motor
(4-pole) capacity
(kW)
VLD 1.52.23.75.57.5111518.522303745557590110132160
LD 1.52.23.75.57.5111518.522303745557590110132160
ND 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75 90 110 132
Output
Rated output
current (A)
VLD 4.1 5.4 8.3 12.6 17.5 25.0 31.0 40.0 47.0 62.0 77.0 93.0 116 147 176 213 252 316
LD 3.1 4.8 6.7 11.1 16.0 22.0 29.0 37.0 43.0 57.0 70.0 85.0 105 135 160 195 230 290
ND 2.5 4.0 5.5 9.2 14.8 19.0 25.0 32.0 39.0 48.0 61.0 75.0 91.0 112 150 180 217 260
Overload
current
rating
VLD 110% 60sec / 120% 3sec
LD 120% 60sec / 150% 3sec
ND 150% 60sec / 200% 3sec
Rated output
voltage
3-phase (3-wire) 380 to 500V (depending on receiving voltage)
Rated
capacity
(kVA)
400V
VLD 2.8 3.7 5.8 8.7 12.1 17.3 21.5 27.7 32.6 43.0 53.3 64.4 80.4
101.8 121.9 147.6 174.6 218.9
LD 2.1 3.3 4.6 7.7 11.1 15.2 20.1 25.6 29.8 39.5 48.5 58.9 72.7 93.5 110.9
135.1 159.3 200.9
ND 1.7 2.8 3.8 6.4 10.3 13.2 17.3 22.2 27.0 33.3 42.3 52.0 63.0 77.6
103.9 124.7 150.3 180.1
500V
VLD 3.6 4.7 7.2 10.9 15.2 21.7 26.8 34.6 40.7 53.7 66.7 80.5
100.5 127.3 152.4 184.5 218.2 273.7
LD 2.7 4.2 5.8 9.6 13.9 19.1 25.1 32.0 37.2 49.4 60.6 73.6 90.9 116.9
138.6 168.9 199.2 251.1
ND 2.2 3.5 4.8 8.0 12.8 16.5 21.7 27.7 33.8 41.6 52.8 65.0 78.8 97.0
129.9 155.9 187.9 225.2
Input
Rated input
current (A)
*1
VLD 4.9 6.4 9.9 15.0 20.8 29.8 36.9 47.6 56.0 73.8 91.7 110.7
138.1 175.0 209.5 253.6 300.0 376.2
LD 3.7 5.7 8.0 13.2 19.0 26.2 34.5 44.0 51.2 67.9 83.3
101.2 125.0 160.7 190.5 232.1 273.8 345.2
ND 3.0 4.8 6.5 11.0 17.6 22.6 29.8 38.1 46.4 57.1 72.6 89.3
108.3 133.3 178.6 214.3 258.3 309.5
Rated input AC
voltage
Control power supply: Power supply single phase 380 to 500V (allowable variation range 323 to 550V),
50Hz (allowable variation range: 47.5 to 52.5Hz)/60Hz (allowable variation range: 57 to 63Hz)
Main circuit power supply: 3-phase (3-wire) 380 to 500V (allowable variation range) 323 to 550V,
50Hz (allowable variation range: 47.5 to 52.5Hz)/60Hz (allowable variation range: 57 to 63Hz)
Power
supply
equipment
capacity
(kVA) *2
VLD 3.7 4.9 7.5 11.4 15.9 22.7 28.1 36.3 42.6 56.3 69.9 84.4
105.2 133.4 159.7 193.2 228.6 286.7
LD 2.8 4.4 6.1 10.1 14.5 20.0 26.3 33.6 39.0 51.7 63.5 77.1 95.3
122.5 145.2 176.9 208.7 263.1
ND 2.3 3.6 5.0 8.3 13.4 17.2 22.7 29.0 35.4 43.5 55.3 68.0 82.6
101.6 136.1 163.3 196.9 235.9
Carrier frequency
range *3
VLD 0.5 to 10.0kHz 0.5 to 8.0kHz
LD 0.5 to 12.0kHz 0.5 to 8.0kHz
ND 0.5 to 16.0kHz 0.5 to 10.0kHz
Motor start torque *4 200%/0.3Hz 180%/0.3Hz
Braki
ng
Regenerative
braking
Equipped with braking resistance circuit
(with a discharging resistor separately installed)
Regenerative braking unit separately
installed
Minimum
resistance that can
be connected (Ω)
100100100707035352424201515 - - - - - -
Protective construction IP20*5 / UL open type IP00 / UL open type
Approximate mass (kg) 3 3 3 3 6 6 68.58.58.52231313141415353
