61F-GP-N@
2
■ Compact Plug-in Models (11-pin Type)
Specifications
Note: 1. The length when using completely insulated, 600-V, 3-conductor (0.75 mm
2
) cabtire cables. Usable cable lengths will become shorter as
the cable diameter or number of conductors becomes larger. For details, refer to Safety Precautions for Floatless Level Controllers.
2. The insulation resistance and dielectric strength indicate values between power terminals and Electrode terminals, between power
terminals and contact terminals, and between Electrode terminals and contact terminals. For details, refer to Safety Precautions for
Floatless Level Controllers.
3. Possible to use with 15 kΩ or less, however, this may cause reset failure.
4. 61F-GP-NH High-sensitivity Controller uses advanced operation.
When the power supply voltage is applied, if there are some liquids between the electrodes (ground and operation electrodes), the inter-
nal relay will not operate.
When the power supply voltage is applied, if there are no liquids between the electrodes (ground and operation electrodes), the internal
relay will operate.
If the advanced operation does not satisfy applications, consider using 61F-N8HY controller which uses sequential operation.
Item General-purpose
Controller
61F-GP-N
High-
temperature
Controller
61F-GP-NT
Long-distance
Controllers
61F-GP-NL 2KM
(for 2 km)
61F-GP-NL 4KM
(for 4 km)
High-sensitivity
Controller
61F-GP-NH
(see note 4)
Low-sensitivity
Controller
61F-GP-ND
Two-wire
Controller
61F-GP-NR
Controlling materials
and operating condi-
tions
For control of ordi-
nary purified water
or sewage water
For control of ordi-
nary purified water
or sewage where
operating ambient
temperature is
high.
For control of ordi-
nary purified water
in cases where the
distance between
sewage pumps
and water tanks or
between receiver
tanks and supply
tanks is long or
where remote con-
trol is required.
For control of liq-
uids with high spe-
cific resistance
such as distilled
water
For control of liq-
uids with low spe-
cific resistance
such as salt water,
sewage water,
acid chemicals, al-
kali chemicals
For control of ordi-
nary purified water
or sewage water
used in combina-
tion with Two-wire
Electrode Holder
(incorporating a
resistor of 6.8 kΩ)
Supply voltage 24, 100, 110, 120, 200, 220, 230 or 240 VAC; 50/60 Hz
Operating voltage
range
85% to 110% of rated voltage
Interelectrode voltage 8 VAC
Interelectrode current Approx. 1 mA AC max. Approx. 0.12 mA
AC max.
Approx. 1 mA AC max.
Power consumption Approx. 3.5 VA max.
Interelectrode operate
resistance
0 to approx. 4 kΩ 0 to approx. 4 kΩ 0 to approx. 1.3 kΩ
(for 2 km)
0 to approx. 0.5 kΩ
(for 4 km)
Approx. 10 kΩ to
approx. 40 kΩ
(see note 3)
0 to approx.
1.3
kΩ
0 to
app
rox. 2 kΩ
Interelectrode release
resistance
Approx. 15 k to
∞Ω
Approx. 15 k to
∞Ω
4 k to ∞Ω (for 2
km)
2.5 k to ∞Ω (for 4
km)
Approx. 100 k to
∞Ω
Approx. 4 k to ∞Ω Approx. 15 k to
∞Ω
Response time Operate:80 ms max.
Release:160 ms max.
Cable length
(see note 1)
1 km max. 600 m max. 2 km max.
4 km max.
50 m max. 1 km max. 800 m max.
Control output 1 A, 250 VAC (Inductive load: cosφ = 0.4)
3 A, 250 VAC (Resistive load)
Ambient temperature Operating:–10 to 55°C (–10 to 70°C for high-temperature controller)
Ambient humidity Operating:45% to 85% RH
Insulation resistance
(see note 2)
100 MΩ min. (at 500 VDC)
Dielectric strength
(see note 2)
2000 VAC, 50/60 Hz for 1 min.
Life expectancy Electrical: 100,000 operations min.
Mechanical: 5,000,000 operations min.
Weight Approx. 155 g
Accessories Hold-down clip PFC-N8
Approved standards UL508, CSA C22.2 No.14, EN61010-1, EN61326-1 Industrial electromagnetic environment
