Omron 61F-GP-N User Manual

61F-GP-N@
12
Water Supply Automatic Drainage
Two-Wire Connections
Automatic Water Supply and Drainage Control
Compact, Plug-in Type
61F-GP-N8R
Dimensions:
page 14
E1
E2
E3
U
U
A
Water supply
source
Stop
Start
MCCB
RS
M
T
61F-GP-N8R
7812
P
8 V
0 V
24 V
PS-3SR
3564
Control
circuit
R
(See note.)
Water
tank
Contac-
tor
Commercial Voltage
Power
supply
Motor
protection
relay
Note: Be sure to ground the common Electrode E3 (the
longest Electrode).
• Connect terminal 2 to the contactor’s coil terminal.
Note: The power supply depends on the specifications of the
model.
• With 2-wire connections, only two wires are required between
the 61F-GP-N8R and Electrode Holder, but three wires are
required for the Electrodes.
• The Electrode Holder must be specified for 2-wire connections.
(Resistance R is built into Electrode Holders for 2-Wire
Connections.)
Connections
E2
E3
U
U
A
Reservoir
MCCB
RS
M
T
61F-GP-N8R
(See
note.)
7812
P
R
8 V
0 V
24 V
PS-3SR
3564
Control
circuit
Stop
Start
E1
Contac-
tor
Commercial Voltage
Power
supply
Motor
protection
relay
Waste-
water
tank
Note: Be sure to ground the common Electrode E3 (the
longest Electrode).
• Connect terminal 3 to the contactor’s coil terminal.
Note: The power supply depends on the specifications of the
model.
• With 2-wire connections, only two wires are required between
the 61F-GP-N8R and Electrode Holder, but three wires are
required for the Electrodes.
• The Electrode Holder must be specified for 2-wire connections.
(Resistance R is built into Electrode Holders for 2-Wire
Connections.)
Connections
E 1
E 2
E 3
P
Water
supply
(Indicator ON)
Pump OFF
Pump ON
(Indicator OFF)
The pump stops when the water level reaches E1 (indicator ON)
and starts when the water level drops below E
2 (indicator OFF).
Principles of Operation
E 1
E 2
E 3
Water drainage
(Indicator ON)
Pump OFF
Pump ON
(Indicator OFF)
P
The pump starts when the water level reaches E1 (indicator ON)
and stops when the water level drops below E
2 (indicator OFF).
Principles of Operation

Omron 61F-GP-N Specifications

General

Control Output	Relay
Contact Configuration	SPDT
Rated Current	5A
Rated Voltage	250 VAC
Operating Force	Not Applicable
Operating Temperature Range	-10 to 55°C
Electrical Life	100, 000 operations
Contact Rating	5A at 250 VAC
Mounting Type	Panel
Electrode	Separate Electrode Required
Mechanical Life	5, 000, 000 operations
Supply Voltage	100/110/120 VAC, 200/220/240 VAC
