Omron C200HX Series User Manual

Appendix AStandard Models
105
Optical Fiber Products
Optical Fiber Cable for SYSMAC NET and SYSMAC LINK
H-PCF Optical Fiber Cable with Connectors
System Appearance Model number
SYSMAC NET
SYSMAC LINK
S3200-CNjjj-20-20
S3200-CNjjj-20-25
S3200-CNjjj-20-62
S3200-CNjjj-25-25
S3200-CNjjj-25-62
S3200-CNjjj-62-62
Model Numbers
The above cable model numbers specify the type of cable, the length, and the type of connectors attached.
S3200-CNjjj-20-25
1. 2. 3.
1. S3200-CN specifies H-PCF optical fiber cable.
2. The boxes (jjj) are replaced by codes indicating the standard model lengths, as shown below.
Consult with your OMRON representative for longer cables. When ordering longer cables, omit the portion
represented by the boxes and specify the length in meters separately, e.g., S3200-CN-20-20, 30 m.
Code Length Code Length
201 2 m 152 15 m
501 5 m 202 20 m
102 10 m Omitted Over 20 m
3. The last two portions of the model numbers (e.g., 20-25) specify the connectors, as shown below.
Code Connector
20 S3200-COCF2011
25 S3200-COCF2511
62 S3200-COCH62M
