Omron CJ1W-AD081-V1 - Input Function Block Diagram; Input Specifications

82
Specifications Section 3-1
3-1-2 Input Function Block Diagram
Note There are only four analog inputs for the CJ1W-AD041-V1.
3-1-3 Input Specifications
If signals that are outside the specified range provided below are input, the
conversion values (16-bit binary data) used will be either the maximum or
minimum value.
Range: 1 to 5 V (4 to 20 mA)
Analog Input Unit CPU Unit
Special I/O
Unit Area
I/O
refresh
Analog input 1
Analog input 2
Same as above.
Input dis-
connection
detection
Mean value
processing
disabled
Mean value
processing
enabled
Peak value
hold function
disabled
A/D
Analog input 3
Analog input 4
Peak value
hold function
enabled
Same as above.
Same as above.
Analog input 5
Same as above.
Analog input 6
Same as above.
Analog input 7
Same as above.
Analog input 8
Same as above.
Conver-
sion value
for Analog
input 1
1 V/4 mA
0.8 V/3.2 mA
5 V/20 mA
5.2 V/20.8 mA
Conversion value
1068 (20D0)
0FA0 (1F40)
0000 (0000)
FF38 (FE70)
Analo
g
input si
g
nal
Resolution: 4,000
(Resolution: 8,000)
