Components and Switch Settings Section 6-3
6-3 Components and Switch Settings
Unit number
setting switch
External terminal
block (M3)
External ter-
minal block
mounting
screws
(black M3)
Front
Mounting to terminal block
Removing from terminal block
Voltage/Current
switch
Operation mode switch
Backplane connector
Terminal block
Side
Back
