14
Specifications Section 2-1
2-1 Specifications
2-1-1 Specifications
Item CS1W-AD041-V1 CS1W-AD081-V1 CS1W-AD161
Unit type CS-series Special I/O Unit
Isolation (See note 1.) Between I/O and PLC signals: Photocoupler
(No isolation between individual I/O signals.)
External terminals 21-point detachable terminal block (M3 screws) Two 34-pin MIL connectors
Affect on CPU Unit cycle time 0.2 ms
Power consumption 120 mA max. at 5 VDC, 90 mA max. at 26 VDC 150 mA max. at 5 VDC,
55 mA max. at 26 VDC
Dimensions (mm) (See note 2.) 35 x 130 x 126 (W x H x D) 35 x 130 x 119 (W x H x D)
Weight 450 g max.
General specifications Conforms to general specifications for SYSMAC CS Series.
Mounting position CS-series CPU Rack or CS-series Expansion Rack
(Cannot be mounted to a C200H Expansion I/O Rack or a SYSMAC BUS Slave
Rack.)
Maximum number of Units
(See note 3.)
Refer to the table on page 15.
Data exchange with CPU Units
(See note 4.)
Special I/O Unit Area in CIO Area (CIO 2000 to CIO
2959): 10 words per Unit
Special I/O Unit Area in DM Area (D20000 to D29599):
100 words per Unit
Special I/O Unit Area in
CIO Area (CIO 2000 to
CIO 2959): 20 words per
Unit
Special I/O Unit Area in
DM Area (D20000 to
D29599): 200 words per
Unit
Input
specifi-
cations
Number of analog inputs 4 8 16
Input signal range
(See note 5.)
1 to 5 V
0 to 5 V
0 to 10 V
–10 to 10 V
4 to 20 mA
(See note 6.)
Maximum rated input (for
1 point) (See note 7.)
Voltage Input: ±15 V
Current Input: ±30 mA
Input impedance Voltage Input: 1 MΩ min.
Current Input: 250 Ω (rated value)
Resolution 4,000/8,000 (See note 8.)
Converted output data 16-bit binary data
Accuracy
(See note
9.)
23±2°C Voltage Input: ±0.2% of full scale
Current Input: ±0.4% of full scale
Voltage Input: ±0.2% of full
scale
Current Input: ±0.2% of full
scale
0°C to 55°C Voltage Input:±0.4% of full scale
Current Input: ±0.6% of full scale
Voltage Input:±0.4% of full
scale
Current Input: ±0.4% of full
scale
A/D conversion time
(See note 10.)
1.0 ms or 250 µs per point max. (See note 8.)
