7
Serial Communications Connection Procedure
7.3.7. Connecting Online and Transferring the Protocol Macro Data
Connect online with CX-Protocol and transfer the protocol macro data to Serial
Communications Unit.
Double-click
P652_CJ_PMCR232C_OMRO
N_ZW-7000_EV100 in the
Project Workspace to display a
tree.
2
Select Edit PC-PLC Comms
Settings from the PLC Menu.
3
The Change PLC Dialog Box is
displayed.
From the pull-down list of Device
Type, select the device type of
PLC to use.
Click Settings.
*CJ2M is selected in this
document.
The Device Type Settings
Dialog Box is displayed.
From the pull-down list of CPU
Type, select the CPU type to
use. Click OK.
*CPU12 is selected in this
document.
To Next Page
