Omron CK3E Series Startup Guide

59
4
[Slot1(NX-SL3500)Input Data
Set1]
Registering Node2
Click New in the Variables tab
page, and register 19 variables
shown on the right.
FSoE Master CMD
#xE700:01
USINT
Group: Module 1(NX-SL3500).Input Data Set 1
Datatype : USINT
Count : 1
STO Command
#x6640:00
BOOL
-
-
BOOL
-
-
BOOL
-
-
BOOL
-
-
BOOL
-
-
BOOL
-
-
BOOL
Error acknowledge
#x6632:00
BOOL
-
-
BOOL
-
-
BOOL
-
-
BOOL
-
-
BOOL
-
-
BOOL
-
-
BOOL
-
-
BOOL
-
-
BOOL
Group: Module 1(NX-SL3500).Input Data Set 1
Datatype : BOOL
Count : 16
FSoE Slave CRC_0
#xE600:03
UINT
FSoE Slave Conn_ID
#xE600:02
UINT
Group: Module 1(NX-SL3500).Input Data Set 1
Datatype : UINT
Count : 2
5
[Slot1(NX-SL3500)Input Data
Set2]
Registering Safety CPU Status
Click New in the Variables tab
page, and register the variable
shown on the right.
Safety CPU Status
#x6004:01
UINT
Group: Module 1(NX-SL3500).Input Data Set 2
Datatype: UINT
Count: 1
