Omron CP2E User Manual

11
Product name Specifications Model
1-port Serial Option Board
RS-232C
CP1W-CIF01
RS-422A/485
CP1W-CIF11
RS-422A/485 (isolated)
CP1W-CIF12-V1
2-port Serial Option Board
*
1
RS-232C 2port
CP2W-CIFD1
RS-232C, RS-485 (isolated)
CP2W-CIFD2
RS-485 (isolated) 2port
CP2W-CIFD3
Analog Option Board
*
1
2 analog inputs. 0 to 10 V (resolution: 1/4000), 0 to 20 mA (resolution: 1/2000)
CP1W-ADB21
2 analog outputs. 0 to 10 V (resolution: 1/4000)
CP1W-DAB21V
2 analog inputs. 0 to 10 V (resolution: 1/4000), 0 to 20 mA (resolution: 1/2000)
2 analog outputs. 0 to 10 V (resolution: 1/4000)
CP1W-MAB221
Product name Specifications License Media Model
CX-One Lite Ver4.□
A subset of the complete CX-One package that provides
only the support software required for compact PLC applications
1 DVD
CXONE-LT01D-V4
Cx-One Ver4.□
A comprehensive software package that integrates support software
for Omron PLCs and components
1 DVD
CXONE-AL01D-V4
Unit type Product name Inputs Outputs Specifications Model
CP1W
Expansion
I/O Unit
Input Unit 8 － 24 VDC input CP1W-8ED
Output Unit
－
8 Relay CP1W-8ER
8 Transistor (sinking) CP1W-8ET
8 Transistor (sourcing) CP1W-8ET1
16 Relay CP1W-16ER
16 Transistor (sinking) CP1W-16ET
16 Transistor (sourcing) CP1W-16ET1
32 Relay CP1W-32ER
32 Transistor (sinking) CP1W-32ET
32 Transistor (sourcing) CP1W-32ET1
I/O Unit
12 8 Relay CP1W-20EDR1
12 8 Transistor (sinking) CP1W-20EDT
12 8 Transistor (sourcing) CP1W-20EDT1
24 16 Relay CP1W-40EDR
24 16 Transistor (sinking) CP1W-40EDT
24 16 Transistor (sourcing) CP1W-40EDT1
CP1W
Expansion
Unit
Analog
Input Unit
4 ch
－
Input range: 0 to 5 V, 1 to 5 V, 0 to 10 V, -10 to 10 V,
0 to 20 mA, or 4 to 20 mA. Resolution: 1/6000
CP1W-AD041
4 ch
Input range: 0 to 5 V, 1 to 5 V, 0 to 10 V, -10 to 10 V,
0 to 20 mA, or 4 to 20 mA. Resolution: 1/12000
CP1W-AD042
Analog Output
Unit
－
2 ch
Output range: 1 to 5 V, 0 to 10 V, -10 to 10 V,
0 to 20 mA, or 4 to 20 mA. Resolution: 1/6000
CP1W-DA021
4 ch CP1W-DA041
4 ch
Output range: 1 to 5 V, 0 to 10 V, -10 to 10 V,
0 to 20 mA, or 4 to 20 mA. Resolution: 1/12000
CP1W-DA042
Analog
I/O Unit
2 ch 1 ch
Input range: 0 to 5 V, 1 to 5 V, 0 to 10 V, -10 to 10 V, 0 to 20 mA, or 4 to 20 mA.
Output range: 1 to 5 V, 0 to 10 V, -10 to 10 V, 0 to 20 mA, or 4 to 20 mA. Resolution: 1/6000
CP1W-MAD11
4 ch 2 ch
Input range: 0 to 5 V, 1 to 5 V, 0 to 10 V, -10 to 10 V, 0 to 20 mA, or 4 to 20 mA.
Output range: 1 to 5 V, 0 to 10 V, -10 to 10 V, 0 to 20 mA, or 4 to 20 mA. Resolution: 1/12000
CP1W-MAD42
4 ch 4 ch CP1W-MAD44
Temperature
Sensor Unit
2 ch
－
Sensor type: Thermocouple (K or J)
CP1W-TS001
4 ch CP1W-TS002
2 ch
Sensor type: Platinum resistance thermometer (Pt100 or JPt100)
CP1W-TS101
4 ch CP1W-TS102
4 ch
Sensor type: Thermocouple (K or J). 4 ch or 2 analog inputs.
Input range: 0 to 10 V, 1 to 5 V, or 4 to 20 mA. Resolution: 1/12000
CP1W-TS003
12 ch Sensor type: Thermocouple (K or J) CP1W-TS004
I/O Connecting Cable
800 mm extension cable for CP1W Expansion I/O Units and CP1W Expansion Units.
Only one I/O Connecting Cable can be used in each PLC
CP1W-CN811
Software
*
1.Two 2-port serial option boards cannot be mounted in a CPU unit. Two analog option boards also cannot be mounted in a CPU unit.
Product name Specifications Model
Battery
CP2E-N, CP2E-S dedicated battery. Install when using the clock function
CP2W-BAT02
Battery: only for Real time Clock function- CP2E-N/CP2E-S CPU Unit
Option Boards for CP2E-N
Optional Products
Expansion I/O Units and Expansion Units

Omron CP2E Specifications

General

Expansion I/O Units	Up to 7 units
Model	CP2E
Type	Programmable Logic Controller (PLC)
Analog Inputs	Available via expansion units
Analog Outputs	Available via expansion units
Communication Ports	RS-232C
Ethernet Port	Yes
Power Supply	100 to 240 VAC or 24 VDC (depending on the model)
