Omron CP2E User Manual

10
I/O points
Specifications
Power supply Inputs Outputs Output type
Program capacity DM Area capacity Model
14
100 to 240 VAC
8 6
Relay
10K steps 16K words
CP2E-N14DR-A
Transistor (sinking) CP2E-N14DT-A
24 VDC
Relay CP2E-N14DR-D
Transistor (sinking) CP2E-N14DT-D
Transistor (sourcing) CP2E-N14DT1-D
20
100 to 240 VAC
12 8
Relay CP2E-N20DR-A
Transistor (sinking) CP2E-N20DT-A
24 VDC
Relay CP2E-N20DR-D
Transistor (sinking) CP2E-N20DT-D
Transistor (sourcing) CP2E-N20DT1-D
30
100 to 240 VAC
18 12
Relay CP2E-N30DR-A
Transistor (sinking) CP2E-N30DT-A
24 VDC
Relay CP2E-N30DR-D
Transistor (sinking) CP2E-N30DT-D
Transistor (sourcing) CP2E-N30DT1-D
40
100 to 240 VAC
24 16
Relay CP2E-N40DR-A
Transistor (sinking) CP2E-N40DT-A
24 VDC
Relay CP2E-N40DR-D
Transistor (sinking) CP2E-N40DT-D
Transistor (sourcing) CP2E-N40DT1-D
60
100 to 240 VAC
36 24
Relay CP2E-N60DR-A
Transistor (sinking) CP2E-N60DT-A
24 VDC
Relay CP2E-N60DR-D
Transistor (sinking) CP2E-N60DT-D
Transistor (sourcing) CP2E-N60DT1-D
I/O points
Specifications
Power supply Inputs Outputs Output type
Program capacity DM Area capacity Model
30
100 to 240 VAC
18 12
Relay
8K steps 8K words
CP2E-S30DR-A
24 VDC
Transistor (sinking) CP2E-S30DT-D
Transistor (sourcing) CP2E-S30DT1-D
40
100 to 240 VAC
24 16
Relay CP2E-S40DR-A
24 VDC
Transistor (sinking) CP2E-S40DT-D
Transistor (sourcing) CP2E-S40DT1-D
60
100 to 240 VAC
36 24
Relay CP2E-S60DR-A
24 VDC
Transistor (sinking) CP2E-S60DT-D
Transistor (sourcing) CP2E-S60DT1-D
I/O points
Specifications
Power supply Inputs Outputs Output type
Program capacity DM Area capacity Model
14
100 to 240 VAC
8 6 Relay
4K steps 4K words
CP2E-E14DR-A
20 12 8 Relay CP2E-E20DR-A
30 18 12 Relay CP2E-E30DR-A
40 24 16 Relay CP2E-E40DR-A
60 36 24 Relay CP2E-E60DR-A
Ordering Information
CP2E-N/Network Models
CP2E-S/Standard Models
CP2E-E/Essential Models
CPU Units
Function Blocks are available to download free of charge from Omron website. (www.ia.omron.com/cp_fb)
FB
For details, refer to datasheet of CP2E (Cat.No. P145).

Omron CP2E Specifications

General

Expansion I/O Units	Up to 7 units
Model	CP2E
Type	Programmable Logic Controller (PLC)
Analog Inputs	Available via expansion units
Analog Outputs	Available via expansion units
Communication Ports	RS-232C
Ethernet Port	Yes
Power Supply	100 to 240 VAC or 24 VDC (depending on the model)
