Omron CP2E User Manual

9
20-point I/O Unit
16-point Output Unit
Analog Input Unit
Analog Output Unit
Analog I/O Unit
12-ch Temperature
Sensor Unit
I/O Connecting Cable
4-ch Temperature
Sensor Unit
2-ch Temperature
Sensor Unit
8-point Input Unit
8-point Output Unit
Battery: only for Real time
Clock function-
CP2E-N/CP2E-S CPU Unit
Option Board (for CP2E-N-type CPU Units)
Expansion I/O Unit and Expansion Unit
Battery
RS-232C
RS-232C
RS-232C
RS-485 (isolated)
RS-485 (isolated)
RS-485 (isolated)
RS-232C RS-422A/485 RS-422A/485
(isolated)
2 analog inputs
0 to 10 V, 0 to 20 mA
2 analog outputs
0 to 10 V
2 analog inputs
0 to 10 V,
0 to 20 mA
2 analog outputs
0 to 10 V
Analog Option Board
*
2
*2. Two 2-port serial option boards cannot be mounted in a CPU unit.
Two analog option boards also cannot be mounted in a CPU unit.
40-point I/O Unit
32-point Output Unit
2-port Serial Option Board
*
2
１-port Serial Option Board

Omron CP2E Specifications

General

Expansion I/O Units	Up to 7 units
Model	CP2E
Type	Programmable Logic Controller (PLC)
Analog Inputs	Available via expansion units
Analog Outputs	Available via expansion units
Communication Ports	RS-232C
Ethernet Port	Yes
Power Supply	100 to 240 VAC or 24 VDC (depending on the model)
