Omron CP2E User Manual

ZEN V2 Units
26
Dimensions
Note: All units are in millimeters unless otherwise indicated.
■ CPU Units
Dimensions with Battery Unit
Q 4
I 6 I 7 I 8 I 9 I a I b
Q 6 Q 5 Q 7
20C1AR-A-V2
60
70
90 80
112.5
122.5
4.7
(Sliding: 13 max.)
90 80
4.7
(Sliding: 13 max.)
60 (112.5) *
80
Two, M 4
4.5
5.5
45
44
56
45
44
56
Unit Mounting Holes
Mounting Hole Dimensions
Note: Use M4 screws
for mounting.
* The dimensions in parentheses
refer to models with 20 I/O points.
CPU Units with 10 I/O Points
ZEN-10C@@@-@-V2
CPU Units with 20 I/O Points
ZEN-20C@@@-@-V2
Q 4
I 6 I 7 I 8 I 9 I a I b
Q 6 Q 5 Q 7
20C1AR-A-V2
ZEN-BAT01
45 45
44
87.5
70
17.5
122.5
17.5
140
CPU Units with 10 I/O Points CPU Units with 20 I/O Points

Omron CP2E Specifications

General

Expansion I/O Units	Up to 7 units
Model	CP2E
Type	Programmable Logic Controller (PLC)
Analog Inputs	Available via expansion units
Analog Outputs	Available via expansion units
Communication Ports	RS-232C
Ethernet Port	Yes
Power Supply	100 to 240 VAC or 24 VDC (depending on the model)
