Omron CS Series Operator's Manual

I/O Memory Allocation Section 9-3
221
Address CS/CJ-series PLC CX-Simulator
Words Bits
Name
Function Settings Function Settings
A417 A41700
to
A41715
CS/CJ-
series CPU
Bus Unit
Error, Unit
Number
Flags
When an error occurs in a data
exchange between the CPU Unit
and a CS/CJ-series CPU Bus
Unit, the CS/CJ-series CPU Bus
Unit Error Flag (A40207) is
turned ON and the bit in A417
corresponding to the unit number
of the Unit where the error oc-
curred is turned ON. Bits 00 to 15
correspond to unit numbers 0 to
F.
The CPU Unit will continue oper-
ating and the ERR/ALM indicator
on the front of the CPU Unit will
flash.
1: Error
0: No error
Not used.
A418 to
A423
A41800
to
A42315
Special I/O
Unit Error,
Unit Num-
ber Flags
When an error occurs in a data
exchange between the CPU Unit
and a Special I/O Unit, the Spe-
cial I/O Unit Error Flag (A40206)
will be turned ON.
1: Error
0: No error
Not used.
A424 A42400
to
A42415
Inner Board
Error In-
formation
When an error occurs in a data
exchange between the CPU Unit
and the Inner Board, the Inner
Board Error Flag (A40208) and
the appropriate bits in A424 will
be turned ON.
· The meaning of the bits in
A424 depends upon the model of
Inner Board that is being used.
Refer to the Board’s operation
manual for details.
A424 will be cleared when the
error is cleared.
Not used.
A42504
to
A42506
When there is an error in a Slave
Rack, these bits contain the
Slave’s unit number.
0 to 4 Hex
(Unit No. 0
to 4)
Not used.
A42504 When there is an error in an Op-
tical I/O Unit (excluding Slave
Racks), the status of A42504
(ON or OFF) indicates whether
the Unit is allocated high or low
bytes.
1: High
0: Low
Same as
CS/CJ-series
PLC.
When there is an error in a Slave
Rack, this byte contains the 2-
digit hexadecimal unit number of
the Master to which the Slave is
connected.
B0: Unit 0
B1: Unit 1
A425
A42508
to
A42515
Slave
Number of
SYSMAC
BUS Error
After Start-
up
When there is an error in an Op-
tical I/O Unit, this byte contains
its 2-digit hexadecimal unit num-
ber (00 to 1F, or 0 to 31 decimal).
00 to 1F
hex (0 to
31)
Same as
CS/CJ-series
PLC.
