Omron CS Series Operator's Manual

I/O Memory Allocation Section 9-3
224
Address CS/CJ-series PLC CX-Simulator
Words Bits
Name
Function Settings Function Settings
A50014 Error Log
Reset Bit
Turn this bit ON to reset the Error
Log Pointer (A300) to 00.
The contents of the Error Log
Area itself (A100 to A199) are not
cleared. These words can be
cleared from a Programming
Device or by writing 0000 to all of
the words.
(This bit is automatically reset to
0 after the Error Log Pointer is
reset.)
0à1: Clear Same as
CS/CJ-series
PLC.
Not reset
in the
Program
mode.
A500
A50015 Output OFF
Bit
Turn this bit ON to turn OFF all
outputs from Basic I/O Units and
Special I/O Units.
Not used.
A501 A50100
to
A50115
CS/CJ-
series CPU
Bus Unit
Restart Bits
Turn these bits ON to restart
(initialize) the CS/CJ-series CPU
Bus Unit with the corresponding
unit number. Bits 00 to 15 corre-
spond to unit numbers 0 to F.
When a restart bit is turned ON,
the corresponding CS/CJ-series
CPU Bus Unit Initializing Flag
(A30200 to A30215) will be
turned ON. Both the restart bit
and initializing flag will be turned
OFF automatically when initiali-
zation is completed.
0 to 1: Re-
start
1 to 0: Re-
start com-
pleted
Turned
OFF by the
system
when the
Unit has
been re-
started.
Not used.
A502 to
A507
A50200
to
A50715
Special I/O
Unit Restart
Bits
Turn these bits ON to restart
(initialize) the Special I/O Unit
with the corresponding unit num-
ber.
0 to 1: Re-
start
1 to 0: Re-
start com-
pleted
Turned
OFF by the
system
when the
Unit has
been re-
started.
Not used.
A50809 Differenti-
ate Monitor
Completed
Flag
ON when the differentiate moni-
tor condition has been estab-
lished during execution of differ-
entiation monitoring.
(This flag will be cleared to 0
when differentiation monitoring
starts.)
1: Monitor
condition
established
0: Not yet
established
Same as
CS/CJ-series
PLC.
A508
A50811 Trace Trig-
ger Monitor
Flag
ON when a trigger condition is
established by the Trace Start Bit
(A50814). OFF when the next
Data Trace is started by the
Sampling Start Bit (A50815).
1: Trigger
condition
established
0: Not yet
established
or not trac-
ing
Same as
CS/CJ-series
PLC.
