vi
About Upgrades:
Version 1.1
The following functions have been added to the CX-Simulator with the upgrade from Version 1.0 to
Version 1.1.
Actual Serial Communications Possible
In Ver.1.0, the contents of messages sent by serial communications instruc-
tions are displayed on the computer screen. In Ver.1.1, actual serial commu-
nications to an external serial communications device connected to a COM
port on the computer are also possible.
NT Link (1:N Mode) Possible
In Ver.1.1, communications with OMRON’s Programmable Terminal (PT)
connected to a COM port on the computer via NT Link are possible.
Multipoint Data Collection Tool Added
Time-series I/O memory data acquired from the actual PLC can be saved as
a Data Replay File (CSV format). Unlike Data Trace, data can not be ac-
quired every cycle. However, data of more than 50 words can be acquired.
WindowsMe/2000 Supported
Serial Number Entry on Installing Added
Version 1.2
The following functions have been added to the CX-Simulator with the upgrade from Version 1.1 to
Version 1.2.
New PLCs Supported
Simulation is newly supported for the following PLCs.
Series CPU Unit model numbers
CS CS1H-CPU67H/66H/65H/64H/63H
CS1G-CPU45H/44H/43H/42H
CJ CJ1H-CPU66H/65H
CJ1G-CPU45H/44H/43H/42H
CJ1G-CPU45/44
Functionality Improved
The following functions have been improved so that the same operation as
that performed by the actual PLC is performed by the CX-Simulator. (There
were some differences in operation with version 1.1.)
• Processing when using index registers for automatic incrementing or
decrementing with sequence output instructions.
• Processing the current EM bank is changed during execution of the lad-
der program.
• Break processing for nested FOR-NEXT loops.
• Processing for decrementing counters in certain ladder program struc-
tures.
