Omron E2E User Manual

3E2E
DC 3-wire/Pre-wired Models
Note: 1. Cables with a length of 5 m are also available. Specify the cable length
at the end of the model number (e.g., E2E-X2E1 5M).
2. Models with a robotics cable are also available. These models are
E2E-X@E1-R (e.g., E2E-X5E1-R).
3. Models with a different frequency are also available. These models are
E2E-X@E@5 (e.g., E2E-X5E15).
4. These models have e-CON connectors (0.3 m cable length), which is
indicated by the suffix “-ECON” (e.g., E2E-X2E1-ECON).
AC 2-wire/Pre-wired Models
Note: 1. Models with a different frequency are also available. These models are
E2E-X@Y@5 (e.g., E2E-X5Y15).
2. Cables with a length of 5 m are also available. Specify the cable length
at the end of the model number (e.g., E2E-X2Y1 5M).
Size Sensing
distance
Output
configuration
Model
Shielded M8 1.5 mm NPN NO
E2E-X1R5E1
(See notes 1 and 2.)
NPN NC
E2E-X1R5E2
PNP NO
E2E-X1R5F1
PNP NC
E2E-X1R5F2
M12 2 mm NPN NO
E2E-X2E1
(See notes 1, 2, 3,
and 4.)
NPN NC
E2E-X2E2
(See notes 3 and 4.)
PNP NO
E2E-X2F1
PNP NC
E2E-X2F2
M18 5 mm NPN NO
E2E-X5E1
(See notes 1, 2, 3,
and 4.)
NPN NC
E2E-X5E2
(See notes 3 and 4.)
PNP NO
E2E-X5F1
PNP NC
E2E-X5F2
M30 10 mm NPN NO
E2E-X10E1
(See notes 1, 2, 3,
and 4.)
NPN NC
E2E-X10E2
(See notes 3 and 4.)
PNP NO
E2E-X10F1
PNP NC
E2E-X10F2
Unshielded M8 2 mm NPN NO
E2E-X2ME1
(See note 2.)
NPN NC
E2E-X2ME2
PNP NO
E2E-X2MF1
PNP NC
E2E-X2MF2
M12 5 mm NPN NO
E2E-X5ME1
(See notes 1, 2, 3,
and 4.)
NPN NC
E2E-X5ME2
(See notes 3 and 4.)
PNP NO
E2E-X5MF1
PNP NC
E2E-X5MF2
M18 10 mm NPN NO
E2E-X10ME1
(See notes 1, 2, 3,
and 4.)
NPN NC
E2E-X10ME2
(see notes 3 and 4.)
PNP NO
E2E-X10MF1
PNP NC
E2E-X10MF2
M30 18 mm NPN NO
E2E-X18ME1
(See notes 1, 2, 3,
and 4.)
NPN NC
E2E-X18ME2
(See notes 3 and 4.)
PNP NO
E2E-X18MF1
PNP NC
E2E-X18MF2
Size Sensing
distance
Operation
mode
Model
Shielded M8 1.5 mm NO E2E-X1R5Y1
NC E2E-X1R5Y2
M12 2 mm NO E2E-X2Y1
(See notes 1 and
2.)
NC E2E-X2Y2
M18 5 mm NO E2E-X5Y1
(See notes 1 and
2.)
NC E2E-X5Y2
M30 10 mm NO E2E-X10Y1
(See notes 1 and
2.)
NC E2E-X10Y2
Unshielded M8 2 mm NO E2E-X2MY1
NC E2E-X2MY2
M12 5 mm NO E2E-X5MY1
(See notes 1 and
2.)
NC E2E-X5MY2
M18 10 mm NO E2E-X10MY1
(See note 1.)
NC E2E-X10MY2
M30 18 mm NO E2E-X18MY1
(See note 1.)
NC E2E-X18MY2

Omron E2E Specifications

General

Type	Inductive Proximity Sensor
Output Type	NPN or PNP
Connection Method	Connector
Operating Voltage	10-30V DC
Hysteresis	10% max of sensing distance
Housing Material	Stainless Steel
Protection Circuits	Reverse polarity protection, Short-circuit protection
Protection Structure	IP67
Operating Temperature	-25°C to +70°C
Current Consumption	10mA max
