E3M-V
E3M-V
12
 SENSOR CABLES
Single-end Connector (Straight Model)
Single-end Connector (L-shaped Model)
XS2F-D422-D80-A (2 m)
XS2F-D422-G80-A (5 m)
5 (0.20)
dia.
14.9 (0.59)
dia.
6 (0.24) dia.
Y96E43SD2 (2 m)
Y96E43SD5 (5 m)
40.7
(1.60)
M12
45°
50
(1.97)
L
30
(1.18)
5
(0.20)
6 (0.24) dia.
5 (0.20)
dia.
50
(1.97)
30
(1.18)
5
(0.20)
L
25.3
(1.00)
28.3
(1.11)
M12
45°
Installation
 SENSOR CABLE
Pin No. Cord wire colors
DC/AC
Brown
Blue
Black
Classification Wire color Connector pin No. Use
DC
Brown 1 (+V)
White 2 Remote
control
Blue 3 (0V)
Black 4 Output
