 STANDARD TARGET OBJECT
(COLOR VS. MUNSELL)
Munsell color notation11 standard colors
White
Red
Yellow red
Yellow green
Yellow
Green
Blue green
Blue
Purple
Red purple
N9.5
4R, 4.5/12.0
4YR, 6.0/11.5
5Y, 8.5/11.0
3GY, 6.5/10.0
3G, 6.5/9.0
5BG, 4.5/10.0
3PB, 5.0/10.0
7P, 5.0/10.0
6RP, 4.5/12.5
Black N2.0
 INSTALLATION
Glossy Target Objects
Incline the Sensor for glossy objects to reduce mirror reflection for
stable sensing operation.
Target object
Target object
5 to 15°
5 to 15°
A
A
B
B
E3M-VG1 E3M-VG2
View AA
View BB
