A Appendices
A - 44
E3NW-ECT EtherCAT Digital Sensor Communication Unit Operation Manual (E429)
This object executes the Sensor initialization command for the Sensor with the unit number that is
specified by the index.
Set this object to 0001 hex to write data. It is always set to 0000 hex when reading data.
To initialize the Sensor during operation, use this command to initialize the Sensor. Do not use the
buttons on the Sensor.
The channel display, display blinking, emission OFF, and flashing settings are not initialized when the
Sensor is initialized.
This object sets the self trigger level of the Sensor with the unit number that is specified by the index.
*1 Items with asterisks are supported from E3NW-ECT version 1.08.
*2 Writing to EEPROM setting (FA0/MA0/TA0)
This object executes the Tuning with workpiece absent command for the Sensor with the unit number
that is specified by the index.
Set this object to 0001 hex to write data. It is always set to 0000 hex when reading data.
Execute the first point of 2-point tuning with workpiece absent first.
4042 + (N-1) × 80
hex
No_01 ... 30 Sensor Initialization
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Sensor Initialization
Range: 0000 to 0001 hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
4050 + (N-1) × 80
hex
No_01 ... 30 Self Trigger Level and Scaling Setting *1/Writing to EEPROM setting *1 *2
Subindex 0: Number of Entries
Range: 01 hex Unit: --- Default: 01 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Self Trigger Level and Scaling Setting */Writing to EEPROM setting *
Range: 1,999 to 9,999
(F831 to 270F hex)
Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (INT16) Access: RW PDO map: Not possible
Data Setting
0000 hex OFF
0001 hex ON
0002 to FFFF hex Not used.
4051 + (N-1) × 80
hex
No_01 ... 30 Tuning with workpiece absent
Subindex 0: Number of Entries
Range: 02 hex Unit: --- Default: 02 hex Attribute: ---
Size: 1 byte (U8) Access: RO PDO map: Not possible
Subindex 1: No_01 ... 30 Tuning with workpiece absent IN1
Range: 0000 to 0001 hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
Sub-index 2: No_01 ... 30 Tuning with workpiece absent IN2
Range: 0000 to 0001 hex Unit: --- Default: --- hex Attribute: A
Size: 2 bytes (U16) Access: RW PDO map: Not possible
