7 Function Specifications
E3NW-ECT EtherCAT Digital Sensor Communication Unit Operation Manual (E429)
7-3 Mounting Dimensions
7
7-3 Mounting Dimensions
The mounting dimensions are shown below.
E3NW-ECT
Power Connector (Accessories)
(FK-MCP 1,5/2-STF-3,5 AU)
Communication Connector
(IN)
Communication Connector
(OUT)
Connector Cover
Communication
Connector (Accessories)
(FK-MCP 1,5/2-STF-3,5 AU)
(4.2)
DIN RAIL (OPTION)
(PFP-N)
(28.6)
38.8
(43)
41
18
46.6
64.5
86.6
15.4
60.9
10
10
102.5
105.1
13.5 9.5
32.5
13.1
(36.7)
93.8
32.2
(35)
36.7
(49.8)
52.7
19.5
E3NW-DS
0.6
0.2
13.1
Cap and connector
Connector (provided)
(FK-MCP 1,5/4-STF-3,5 AU)
49
69
86.9
34.3
25.4
42.9
52.8
36.7
(35)
(44.5)
PFP-N DIN Track
(sold separately)
