Photoelectric Sensors
Dimensions
Amplifier Units
Amplifier Units with Cables
E3X-MDA11
MDA41
CH1
CH2
Four, 2.4 dia.
15.1
32.8
29.8
12.15 3.25
3.9 × 3 = 11.7
3.9 × 3
= 11.7
12.5
4.3
70
32
9.9
3.4
44.3
18.7 34.8
28.1 16
3.4
4.4
1628.1
4.5
10
7
5.65
4.5
16
Two, M3
E3X-MDA11
E3X-MDA41
Main display Sub-display
Vinyl-insulated round cable
Standard length: 2 m*
*Cable Specifications
A 4-dia., 2-conductor (conductor cross-sectional
area: 0.2 mm
2
; insulation diameter: 1.1 mm)
With Mounting Bracket Attached
The Mounting Bracket can also be used on
this side.
Hole for optical communications
Mounting Holes
Second operation indicatorFirst operation indicator
