E3X-MDA
E3X-MDA
Accessories (Order Separately)
Mounting Bracket
End Plate
Specifications
Ratings/Characteristics
Amplifier Units
Appearance Model Quantity
E39-L143 1
Appearance Model Quantity
PFP-M 1
Type 2-channel models
Model NPN output E3X-MDA11 E3X-MDA6
Item PNP output E3X-MDA41 E3X-MDA8
Light source (wavelength) Red LED (650 nm)
Supply voltage 12 to 24 VDC ±10%, ripple (p-p) 10% max.
Power consumption
1,080 mW max.
(current consumption: 45 mA max. at power supply voltage of 24 VDC)
Control output
Load power supply voltage: 26.4 VDC; open collector;
load current: 50 mA max.; residual voltage: 1 V max.
Circuit protection Reverse polarity for power supply connection, output short-circuit
Response
time
Super-
high-
speed
mode
NPN
130 µs
*1
for operation and reset respectively
PNP
Standard mode 1 ms for operation and reset respectively
High-resolution mode 4 ms for operation and reset respectively
Sensitivity setting Teaching or manual method
Functions
Power tuning Light emission power and reception gain, digital control method
Timer function
Select from OFF-delay, ON-delay, or one-shot timer.
1 ms to 5 s (1 to 20 ms set in 1-ms increments, 20 to 200 ms set in 10-ms increments,
200 ms to 1 s set in 100-ms increments, and 1 to 5 s set in 1 s-increments)
Automatic power con-
trol (APC)
High-speed control method for emission current
Zero-reset Display can be reset to zero when required (negative values can be displayed).
Initial reset Settings can be returned to defaults as required.
Mutual interference
prevention
Possible for up to 9 Units (18 channels)
*2, *3
I/O settings
Output setting (Select from channel 2 output, AND, OR, leading edge sync, falling edge sync, or
differential output)
Display Operation indicator for channel 1 (orange), Operation indicator for channel 2 (orange)
Digital display
Select from the following: Incident level for channel 1 + incident level for channel 2, Incident level
+ threshold, incident level percentage + threshold, incident light peak level + no incident light bot-
tom level, minimum incident light peak level + maximum no incident light bottom level, long bar
display, incident level + peak hold, incident level + channel
Display orientation Switching between normal/reversed display is possible.
Ambient illumination
(receiver side)
Incandescent lamp:10,000 lux max.
Sunlight:20,000 lux max.
