Photoelectric Sensors
*1: When differential output is selected for the output setting, the second channel output is 200 µs for operation and reset respectively.
*2: Communications are disabled if the detection mode is selected during super-high-speed mode, and the communications functions for mutual
interference prevention and the Mobile Console will not function.
*3: Mutual interference prevention can be used for up to 5 Units (10 channels) if power tuning is enabled.
Amplifier Unit Connectors
Mobile Console
Ambient temperature
Operating:Groups of 1 to 2 Amplifiers: −25°C to 55°C
Groups of 3 to 10 Amplifiers: −25°C to 50°C
Groups of 11 to 16 Amplifiers: −25°C to 45°C
(with no icing or condensation)
Storage: −30°C to 70°C (with no icing or condensation)
Ambient humidity Operating and storage: 35% to 85% (with no condensation)
Insulation resistance 20 MΩ min. (at 500 VDC)
Dielectric strength 1,000 VAC at 50/60 Hz for 1 minute
Vibration resistance (destruction) 10 to 55 Hz with a 1.5-mm double amplitude for 2 hrs each in X, Y and Z directions
Shock resistance (destruction) 500 m/s
2
, for 3 times each in X, Y and Z directions
Enclosure rating IEC 60529 IP50 (with Protective Cover attached)
Connection method Prewired cable Standard connector
Weight (packed state) Approx. 100 g Approx. 55 g
Materials
Case Polybutylene terephthalate (PBT)
Cover Polycarbonate (PC)
Accessories Instruction sheet
Item E3X-CN11/21/22 E3X-CN12
Rated current 2.5 A
Rated voltage 50 V
Contact resistance 20 mΩ max. (20 mVDC max., 100 mA max.)
(The figure is for connection to the Amplifier Unit and the adjacent Connector. It does not include the conductor resistance
of the cable.)
No. of insertions
(destruction)
50 times
(The figure for the number of insertions is for connection to the Amplifier Unit and the adjacent Connector.)
Materials Housing Polybutylene terephthalate (PBT)
Contacts Phosphor bronze/gold-plated nickel
Weight (packed state) Approx. 55 g Approx. 25 g
Item E3X-MC11-S
Supply voltage Charged with AC adapter
Connection method Connected via adapter
Weight (packed state) Approx. 580 g (Console only: 120 g)
Refer to Operation Manual provided with the Mobile Console for de-
tails.
Type 2-channel models
Model NPN output E3X-MDA11 E3X-MDA6
Item PNP output E3X-MDA41 E3X-MDA8
