Omron E3X-MDA11 User Manual

Photoelectric Sensors
Slave Connectors
s
Mobile Console
14.4
2.6
3
6
2.9
10
0.8
8.4
6.8
10.7
2,000
50
30±
2
E3X-CN12: 2.6 dia.
E3X-CN22: 4 dia.
10±
2
4
15.1
6
*
+5
0
+50
0
E3X-CN12
E3X-CN22
*E3X-CN12: A 2.6-dia., single-conductor, vinyl-insulated round cable (conductor cross-
sectional area: 0.2 mm
2
; insulation diameter: 1.1 mm) is used.
E3X-CN22: A 4-dia., 2-conductor, vinyl-insulated round cable (conductor cross-
sectional area: 0.2 mm
2
; insulation diameter: 1.1 mm) is used.
136
50
52.8
22
Optical communications connection indicator
Sensor
operation
indicator
Main display
Sub-display
RIGHT key
ESC/PWR
key
Operation keys
ENT
key
LEFT
key
UP key
DOWN
key
20
28.8
13.2
31.2
9.9
27.7
17.3
1.2
5.1
12.3
36.7
51.3
5.6
24.3
30.3
31.8
16.3
13.1
(38.2)
10
AC adapter jack
Communications jack
Menu indicators
Channel indicator
M5 ball plunger
Battery
indicators
Channel
buttons
Optical communi-
cations position
Communications jack
E3X-MC11-S
Mobile Console
Mobile Console Head
