E3X-NH
E3X-NH
3
Specifications
Description General-purpose models Timer-function models
Part number E3X-NH11 E3X-NH41 E3X-NH21 E3X-NH51
Light source Red (680 nm)
Supply voltage 12--24 VDC +10% ripple (p-p) 10 % max.
Output NPN PNP NPN PNP
Timing —— 40 ms off delay
Indicator Operation indicator (orange LED), 8-level incident level indicator (green LED), 13-level
threshold indicator (red LED)
Circuit protection Output short-circuit protection, reverse polarity on supply
Operation mode Light ON and Dark ON, switch-selectable
Ambient light immunity
Incandescen
tlamp
3,000 ℓxmax.
Sunlight 10,000 ℓxmax.
Ambient temperature
Operating -- 2 5 °Cto55°C(--13°F to 131°F) with no icing
Storage -- 4 0 °Cto70°C(--40°F to 158°F) with no icing
Ambient humidity Operating 35% to 85% (with no condensation)
Dielectric strength 1,000 VAC at 50/60 Hz for 1 minute
Vibration resistance 10 to 55 Hz, 1.5-mm double amplitude or 300 m/s
2
(approx. 30G) for 2 hrs each in X, Y, and
Z directions
Insulation resistance 20 MΩ min. (at 500 VDC)
Shock resistance 500 m/s
2
(approx. 50G) for 3 times each in X, Y, and Z axis
Enclosure rating IEC IP50
Connection method 2m cable
Material
Case PBT
Cover Polycarbonate
Weight (with 2 m cable) Approx. 100 g
Accessory Mounting brackets (included)
