Omron E3Z series Network Connection Guide

7
．
IO-Link Connection Procedure
32
5
CX-ConfiguratorFDT starts.
Right-click MyNetwork in the
Network View and select Add from
the menu.
6
The Add Dialog Box is displayed.
Select Nx built-in EtherCAT.
Click Yes.
7
Check that <OMRON EtherCAT>
Nx built-in EtherCAT is added under
MyNetwork in the Network View.

Omron E3Z series Specifications

General

Protection Rating	IP67
Response Time	1 ms or less
Accessory Type	Photoelectric Sensor
Connection Type	Pre-wired, Connector
Sensing Method	Through-beam, Retro-reflective, Diffuse-reflective
Light Source	Infrared LED, Red LED
Power Supply Voltage	12 to 24 VDC
Output Type	NPN, PNP
Operating Temperature	-25 to 55°C
Sensing Distance	varies by model (up to 30m for Through-beam)
