Omron E5 Z Series Manual

24 Digital Temperature Controllers E5AZ/E5EZ/E5CZ
Parameters
Parameters related to setting items for each level are marked in
boxes in the flowcharts and brief descriptions are given as required.
At the end of each setting item, press the mode key to return to the
beginning of each level.
Control stops.
Initial setting level
Less than 1 s
Power ON
Operation level
Protect level
Control in progress
Control stopped
Adjustment level
Level change
Less than 1 s
key
key
key
key
key
+ key
+ key
+ key
+ key
1 s min. 3 s min.
1 s min.
Display flashes when key held
down for more than 1 s
.
Communica-
tions setting
level
Password input
set value "−169"
Advanced function
setting level
Display flashes
when key pressed.
3 s min.
The time taken to
move to the protect
level can be adjusted
by changing the "Move
to protect level time"
setting.
1 s min.
Display
E5CZ
No. 1 display
No. 2 display
E5EZ
No. 1 display
No. 2 display
E5AZ
No. 1 display
No. 2 display






key 1 s min.
Advanced Function Setting Level
Note: To select advanced
function setting
level, you must
enter the password
("−169") in the initial
setting level.
Parameter initialization
Alarm 2 hysteresis
Alarm 2 open in alarm
Alarm 1 hysteresis
Alarm 1 open in alarm
Multi-SP uses
Event input assignment 2
Event input assignment 1
Number of multi-SP uses
Select 2 or 4.
Heater burnout detection
MV upper limit
ST stable range
Heater burnout hysteresis
Heater burnout latch
Latch after heater
burnout detection
SP ramp set value
Rate of change during ramp
Resets to the default value.
Limitations to MV
For setting deviation.
Alarm 3 hysteresis
Alarm 3 open in alarm
Standby sequence reset method
MV lower limit
Input setting:
Multi-SP/RUN/STOP
Restarting condition
after clearing standby
ON/OFF setting of
alarm output 1
ON/OFF setting of
alarm output 2
ON/OFF setting of
alarm output 3
α
2-PID parameter
Alarm 1 ON delay
Alarm 2 ON delay
Alarm 3 ON delay
Move to protect level time
Input error output
Cold junction
compensating method
MB command logic
switching
Input digital filter
Additional PV display
Displayed first in the operation level
MV display
Automatic return of display mode
Alarm
ON/OFF
delays
Alarm 1 OFF delay
Alarm 2 OFF delay
Alarm 3 OFF delay
