Digital Temperature Controllers E5AZ 3
Ordering Information
■ List of Models
■ Output Modules
■ Option Units
The E5AZ provides optional functions when an E53-AZM Option Board is mounted along with the following Option Units.
■ Accessories (Order Separately)
Current Transformers (CTs)
Specifications
■ Ratings
Size Power supply voltage Number of alarm
points
Control outputs Model
1/4 DIN
96
× 96 × 78 mm (W × H × D)
100 to 240 VAC 3 Relay E5AZ-R3
Voltage (for driving SSR) E5AZ-Q3
Current E5AZ-C3
Additional control output E5AZ-A3
Type Model
Relay E53-AZR
Voltage E53-AZQ
Current E53-AZC
Functions Model
Option Board E53-AZM
Heater Burnout Alarm E53-AZH
Communications E53-AZ01
E53-AZ03
Event Input E53-AZB
Model E54-CT1 E54-CT3
Hole diameter 5.8 dia. 12.0 dia.
Power supply voltage 100 to 240 VAC, 50/60 Hz
Operating voltage range 85% to 110% of rated supply voltage
Power consumption 10 VA
Sensor input Thermocouple: K, J, T, E, L, U, N, R, S, B
Platinum resistance thermometer: Pt100, JPt100
Infrared temperature sensor: 10 to 70
°C, 60 to 120°C, 115 to 165°C, 140 to 260°C
Voltage input: 0 to 50 mV
Control outputs Relay outputs SPST-NO, 250 VAC, 5 A (resistive load), electrical life: 100,000 operations
Voltage outputs
12 VDC
+15%
/
−20%
(PNP), max. load current: 40 mA, with short-circuit protection circuit
Current outputs 4 to 20 mA DC, load: 600
Ω max., resolution: approx. 2,600
Alarm output SPST-NO, 250 VAC, 2 A (resistive load), electrical life: 100,000 operations
Event input Contact input ON: 1 k
Ω max., OFF: 100 kΩ min.
Non-contact input ON: Residual voltage: 1.5 V max., OFF: Leakage current: 0.1 mA max.
Outflow current: Approx. 7 mA per point
Control method 2-PID control or ON/OFF control
Setting method Digital setting using front panel keys
Indication method 7-segment digital display and single-lighting indicators
Character height: PV: 15.0 mm; SV: 9.5 mm
Other functions According to Controller model
Ambient operating temperature
−10 to 55°C (with no condensation or icing)
Ambient operating humidity 25% to 85%
Storage temperature
−25 to 65°C (with no condensation or icing)
