Digital Temperature Controllers E5EZ 7
Digital Temperature Controllers
E5EZ
Next-generation Digital Temperature
Controller
• Depth of only 78 mm.
• Various temperature inputs: thermocouple, platinum resistance
thermometer, infrared temperature sensor, and analog inputs.
• Auto-tuning and self-tuning are available. Auto-tuning is possi-
ble even while self-tuning is being executed.
• Heating or heating/cooling control is available.
• Event input allows multi-SP selection and run/stop function.
• Modular output cards.
• Time delay alarm function.
• Communications function.
• CE marking and UL/CSA approval.
Refer to the "Safety Precautions" on page 52.
48 × 96 × 78 mm (W × H × D)
®
Model Number Structure
■ Model Number Legend
1. Output type
R: Relay
Q: Voltage (for driving SSR)
C: Current
A: Output Unit can be mounted
2. Number of alarms
3: Three alarms
3. Option 1
Blank: Not available
H: Heater Burnout Alarm
4. Option 2
Blank: Not available
01: RS-232C
02: RS-485
B: 2 event inputs
Note: Options 1 and 2 are available when using an E53-AZM Option
Board.
12 34
E5EZ- @ 3 @ @
