Omron E5CN-H Communications Manual

Com Data
for Modbus
SECTION 6 Communications Data for Modbus
6-4
Note: The alarm function can also be used in Controllers without alarm output terminals. In this case, confirm alarm occurrences via the
status data.
Note 1: The parameter for the currently selected bank will be accessed.
Note 2: Not displayed on the Controller display when Alarm 3 is not assigned to an output.
Note 3: The parameter for the currently selected PID set will be accessed. For setup area 1, however, the currently selected PID set is fixed at
PID1.
Address
Parameter name Setting (monitor) value Level
Four-
byte
mode
Two-
byte
mode
0722 2711 MV at PV Error Standard: H'FFFFFFCE to H'0000041A (
−5.0 to 105.0)
Heating/cooling: H'FFFFFBE6 to H'0000041A (
−105.0 to 105.0)
Position proportional (Floating or direct setting of position propor-
tional MV OFF): H'FFFFFFFF to H'00000001 (
−1 to 1)
Position proportional (Closed and direct setting of position propor-
tional MV ON): H'FFFFFFCE to H'0000041A (
−5.0 to 105.0)
Adjustment
0726 2713 MV Change Rate Limit H'00000000 to H'000003E8 (0.0 to 100.0)
072C 2716 Lower Limit Temperature Input Shift Value H'FFFFB1E1 to H'00007E90 (
−199.99 to 324.00)
0730 2718 Upper Limit Temperature Input Shift Value H'FFFFB1E1 to H'00007E90 (
−199.99 to 324.00)
0734 271A Heater Current 1 Value Monitor H'00000000 to H'00000226 (0.0 to 55.0) Operation
0736 271B Heater Burnout Detection 1 H'00000000 to H'000001F4 (0.0 to 50.0) Adjustment
0738 271C Leakage Current 1 Monitor H'00000000 to H'00000226 (0.0 to 55.0) Operation
073A 271D HS Alarm 1 H'00000000 to H'000001F4 (0.0 to 50.0) Adjustment
0746 2723 Temperature Input Shift H'FFFFB1E1 to H'00007E90 (
−199.99 to 324.00)
0748 2724 Heater Current 2 Value Monitor H'00000000 to H'00000226 (0.0 to 55.0) Operation
074A 2725 Heater Burnout Detection 2 H'00000000 to H'000001F4 (0.0 to 50.0) Adjustment
074C 2726 Leakage Current 2 Monitor H'00000000 to H'00000226 (0.0 to 55.0) Operation
074E 2727 HS Alarm 2 H'00000000 to H'000001F4 (0.0 to 50.0) Adjustment
0750 2728 Soak Time Remain H'00000000 to H'0000270F (0 to 9999) Operation
0752 2729 Soak Time (See note 1.) H'00000000 to H'0000270F (0 to 9999) Adjustment
0754 272A Wait Band (See note 1.) H'00000000 (0): OFF
Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
0756 272B Heater Overcurrent Detection 1 H'00000000 to H'000001F4 (0.0 to 50.0)
0758 272C Heater Overcurrent Detection 2 H'00000000 to H'000001F4 (0.0 to 50.0)
0800 2800 Input Digital Filter H'00000000 to H'0000270F (0.0 to 999.9) Advanced
function
setting
0810 2808 Extraction of Square Root Low-cut Point H'00000000 to H'000003E8 (0.0 to 100.0) Adjustment
0904 2902 Alarm Value 1 (See note 1.) H'FFFFB1E1 to H'00007E90 (
−19999 to 32400) Operation
0906 2903 Alarm Value Upper Limit 1 (See note 1.) H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
0908 2904 Alarm Value Lower Limit 1 (See note 1.) H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
090A 2905 Alarm Value 2 (See note 1.) H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
090C 2906 Alarm Value Upper Limit 2 (See note 1.) H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
090E 2907 Alarm Value Lower Limit 2 (See note 1.) H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
0910 2908 Alarm Value 3 (See notes 1 and 2.) H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
0912 2909 Alarm Value Upper Limit 3 (See notes 1 and 2.) H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
0914 290A Alarm Value Lower Limit 3 (See notes 1 and 2.) H'FFFFB1E1 to H'00007E90 (
−19999 to 32400)
0A00 2A00 Proportional Band (See note 3.) Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.1 to 999.9)
Adjustment
0A02 2A01 Integral Time (See note 3.) Standard, heating/cooling, position proportional (closed):
H'00000000 to H'00007E90 (0.0 to 3240.0)
Position proportional (floating): H'00000001 to H'00007E90
(0.1 to 3240.0)
0A04 2A02 Derivative Time (See note 3.) H'00000000 to H'00007E90 (0.0 to 3240.0)
0A0A 2A05 MV Upper Limit (See note 3.) Standard: MV lower limit +0.1 to H'0000041A
(MV lower limit +0.1 to 105.0)
Heating/cooling: H'00000000 to H'0000041A (0.0 to 105.0)
Position proportional (closed): MV lower limit +0.1 to H'0000041A)
MV lower limit +0.1 to 105.0)
