Omron E5CN-H Communications Manual

Com Data
for Modbus
6.1 Variable Area (Setting Range) List
6-5
Note: The input type can be selected to match the connected sensor.
Note 1: The parameter for the currently selected PID set will be accessed. For setup area 1, however, the currently selected PID
set is fixed at PID1.
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
0A0C 2A06 MV Lower Limit (See note 1.) Standard: H'FFFFFFCE to MV upper limit
−0.1 (−5.0 to MV upper limit −0.1)
Heating/cooling: H'FFFFFBE6 to H'00000000 (
−105.0 to 0.0)
Position proportional (closed):
H'FFFFFFCE to MV upper limit
−0.1 (−5.0 to MV upper limit −0.1)
Adjustment
0C00 2C00 Input Type (See note.) H'00000000 (0): Pt (
−200.0 to 850.0°C/−300.0 to 1500.0°F)
H'00000001 (1): Pt (
−199.9 to 500.0°C/−199.9 to 900.0°F)
H'00000002 (2): Pt (0.0 to 100.0
°C/0.0 to 210.0°F)
H'00000003 (3): JPt (
−199.9 to 500.0°C/−199.9 to 900.0°F)
H'00000004 (4): JPt (0.0 to 100.0
°C/0.0 to 210.0°F)
H'00000005 (5): K (
−200.0 to 1300.0°C/−300.0 to 2300.0°F)
H'00000006 (6): K (
−20.0 to 500.0°C/0.0 to 900.0°F)
H'00000007 (7): J (
−100.0 to 850.0°C/−100.0 to 1500.0°F)
H'00000008 (8): J (
−20.0 to 400.0°C/0.0 to 750.0°F)
H'00000009 (9): T (
−200.0 to 400.0°C/−300.0 to 700.0°F)
H'0000000A (10): T (
−199.9 to 400.0°C/−199.9 to 700.0°F)
H'0000000B (11): E (
−200.0 to 600.0°C/−300.0 to 1100.0°F)
H'0000000C (12): L (
−100.0 to 850.0°C/−100.0 to 1500.0°F)
H'0000000D (13): U (
−200.0 to 400.0°C/−300.0 to 700.0°F)
H'0000000E (14): U (
−199.9 to 400.0°C/−199.9 to 700.0°F)
H'0000000F (15): N (
−200.0 to 1300.0°C/−300.0 to 2300.0°F)
H'00000010 (16): R (0.0 to 1700.0
°C/0.0 to 3000.0°F)
H'00000011 (17): S (0.0 to 1700.0
°C/0.0 to 3000.0°F)
H'00000012 (18): B (100.0 to 1800.0
°C/300.0 to 3200.0°F)
H'00000013 (19): W (0.0 to 2300.0
°C/0.0 to 3200.0°F)
H'00000014 (20): PLII (0.0 to 1300.0
°C/0.0 to 2300.0°F)
H'00000015 (21): K (
−50.00 to 200.00°C/−50.00 to 200.00°F)
H'00000016 (22): J (
−50.00 to 200.00°C/−50.00 to 200.00°F)
H'00000017 (23): T (
−50.00 to 200.00°C/−50.00 to 200.00°F)
H'00000018 (24): Pt (
−50.00 to 200.00°C/−50.00 to 200.00°F)
H'00000019 (25): 4 to 20mA
H'0000001A (26): 0 to 20mA
H'0000001B (27): 1 to 5V
H'0000001C (28): 0 to 5V
H'0000001D (29): 0 to 10V
Initial
setting
0C02 2C01 Temperature Unit H'00000000 (0): °C
H'00000001 (1): °F
0C12 2C09 Scaling Lower Limit H'FFFFB1E1 to Scaling upper limit
−1
(
−19999 to Scaling upper limit −1)
0C16 2C0B Scaling Upper Limit Scaling lower limit +1 to H'00007E90
(Scaling lower limit +1 to 32400)
0C18 2C0C Decimal Point H'00000000 to 00000003 (0 to 3)
0C1A 2C0D Remote SP Upper Limit SP lower limit to SP upper limit Advanced
function
setting
0C1C 2C0E Remote SP Lower Limit SP lower limit to SP upper limit
0C1E 2C0F PV Decimal Point Display H'00000000 (0): OFF
H'00000001 (1): ON
0D06 2D03 Linear Current Output H'00000000 (0): 4 to 20 mA
H'00000001 (1): 0 to 20 mA
Initial
setting
0D1E 2D0F SP Upper Limit The range of values without decimal point is as follows:
Temperature: SP lower limit +1 to Input setting range upper limit
Analog: SP lower limit +1 to Scaling upper limit
0D20 2D10 SP Lower Limit The range of values without decimal point is as follows:
Temperature: Input setting range lower limit to SP upper limit
−1
Analog: Scaling lower limit to SP upper limit
−1
