Com Data for
CompoWay/F
SECTION 3 Communications Data for CompoWay/F and SYSWAY
3-2
3.1 Variable Area (Setting Range) List
For communications using a variable type not enclosed in parentheses in the following table, the set
value is double-word data (8 digits). For communications using a variable type enclosed in parentheses,
the set value is single-word data (4 digits).
For example, variable type C0 is double-word data (8 digits), and variable type 80 is single-word
data (4 digits).
Items expressed in hexadecimal in the “Set (monitor) value” column are the setting range for
CompoWay/F communications. The values in parentheses are the actual setting range. Use the values
in parentheses as the setting range for SYSWAY communications. When there is a section reference for
a setting item, refer to that reference for details.
Note 1: Not displayed on the Controller display.
Note 2: When the variable type is 80 (word access), the rightmost 16 bits are read.
Note 3: When the variable type is 80 (word access), the leftmost 16 bits are read.
Variable
type
Address Parameter name Setting (monitor) value Level
C0 (80) 0000 Process Value Temperature: Use the specified range for each sensor.
Analog: Scaling lower limit
−5% FS to Scaling upper limit +5% FS
Operation
C0 (80) 0001 Status (See notes 1 and 2.) See 3.2 Status and Status 2 for details.
C0 (80) 0002 Internal Set Point (See note 1.) SP lower limit to SP upper limit
C0 (80) 0003 Heater Current 1 Value Monitor H'00000000 to H'00000226 (0.0 to 55.0)
C0 (80) 0004 MV Monitor (Heating) Standard: H'FFFFFFCE to H'0000041A (
−5.0 to 105.0)
Heating/cooling: H'00000000 to H'0000041A (0.0 to 105.0)
C0 (80) 0005 MV Monitor (Cooling) H'00000000 to H'0000041A (0.0 to 105.0)
C0 (80) 0006 Heater Current 2 Value Monitor H'00000000 to H'00000226 (0.0 to 55.0)
C0 (80) 0007 Leakage Current 1 Monitor H'00000000 to H'00000226 (0.0 to 55.0)
C0 (80) 0008 Leakage Current 2 Monitor H'00000000 to H'00000226 (0.0 to 55.0)
C0 (80) 0009 Soak Time Remain H'00000000 to H'0000270F (0 to 9999)
C0 (80) 000A Valve Opening Monitor H'FFFFFF9C to H'0000044C (
−10.0 to 110.0)
C0 (80) 000B Remote SP Monitor Remote SP lower limit to remote SP upper limit
C0 (80) 000C Bank No. Monitor H'00000000 to H'00000007 (0 to 7)
C0 (80) 000D PID Set No. Monitor H'00000001 to H'00000008 (1 to 8)
C0 (80) 000E Decimal Point Monitor (See note 1.) H'00000000 to H'00000003 (0 to 3)
C0 (80) 000F Control Output 1 ON/OFF Count Moni-
tor
H'00000000 to H'0000270F (0 to 9999) Advanced
function
setting
C0 (80) 0010 Control Output 2 ON/OFF Count Moni-
tor
H'00000000 to H'0000270F (0 to 9999)
C0 (80) 0011 Status 2 (See notes 1 and 2.) Refer to 3.2 Status and Status 2. Operation
C0 (80) 0012 Status (See notes 1 and 3.) Refer to 3.2 Status and Status 2.
C0 (80) 0013 Status 2 (See notes 1 and 3.) Refer to 3.2 Status and Status 2.
To Next Page
