Note 1: P.END (program end output) can be set even when the program pattern is set to OFF, but the function will be disabled.
Note 2: The output turns ON when the status of either the Control Output 1 ON/OFF Count Alarm or the Control Output 2 ON/OFF
Count Alarm turns ON.
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
0D22 2D11 Standard or Heating/Cooling H'00000000 (0): Standard
H'00000001 (1): Heating/cooling
Initial
setting
0D24 2D12 Direct/Reverse Operation H'00000000 (0): Reverse operation
H'00000001 (1): Direct operation
0D26 2D13 Closed/Floating H'00000000 (0): Floating
H'00000001 (1): Closed
0D28 2D14 PID ON/OFF H'00000000 (0): ON/OFF
H'00000001 (1): 2 PID control
0D2A 2D15 ST H'00000000 (0): OFF
H'00000001 (1): ON
0D2C 2D16 Program Pattern H'00000000 (0): OFF
H'00000001 (1): STOP
H'00000002 (2): CONT
H'00000003 (3): LOOP
0D2E 2D17 Valid Program Bank H'00000000 to H'00000007 (0 to 7)
0E00 2E00 Transfer Output Type H'00000000 (0): OFF
H'00000001 (1): Set point
H'00000002 (2): Set point during SP ramp
H'00000003 (3): PV
H'00000004 (4): MV monitor (heating)
H'00000005 (5): MV monitor (cooling)
H'00000006 (6): Valve Opening
0E0C 2E06 Control Output 1 Assignment When control output 1 is a linear output:
H'00000000 (0): Not assigned.
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
When control output 1 is an ON/OFF output:
H'00000000 (0): Not assigned.
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Program end output (See note 1.)
H'00000007 (7): Control output ON/OFF count alarm (See note 2.)
H'00000008 (8): Work bit 1
H'00000009 (9): Work bit 2
H'0000000A (10): Work bit 3
H'0000000B (11): Work bit 4
H'0000000C (12): Work bit 5
H'0000000D (13): Work bit 6
H'0000000E (14): Work bit 7
H'0000000F (15): Work bit 8
Advanced
function
setting
0E0E 2E07 Control Output 2 Assignment When control output 2 is a linear output: H'00000000 to H'00000002 (0 to 2)
(Same as for Control Output 1 Assignment.)
When control output 2 is an ON/OFF output: H'00000000 to H'0000000F (0 to
15) (Same as for Control Output 1 Assignment.)
