Omron E5CN-H Communications Manual

Com Data
for Modbus
6.1 Variable Area (Setting Range) List
6-9
Note 1: Not displayed on the Controller display when Alarm 3 is not assigned to the output.
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
0F22 2F11 Alarm 1 ON delay H'00000000 to H'000003E7 (0 to 999) Advanced
function
setting
0F24 2F12 Alarm 2 ON delay H'00000000 to H'000003E7 (0 to 999)
0F26 2F13 Alarm 3 ON delay (See note 1.) H'00000000 to H'000003E7 (0 to 999)
0F2A 2F15 Alarm 1 OFF delay H'00000000 to H'000003E7 (0 to 999)
0F2C 2F16 Alarm 2 OFF delay H'00000000 to H'000003E7 (0 to 999)
0F2E 2F17 Alarm 3 OFF delay (See note 1.) H'00000000 to H'000003E7 (0 to 999)
1000 3000 PV/SP Display Screen Selection H'00000000 (0): PV/SP
H'00000001 (1): PV/SP/Bank No.
PV/SP/MV
H'00000002 (2): PV/SP/MV
PV/SP/Bank No.
H'00000003 (3): PV/SP/Bank No.
H'00000004 (4): PV/SP/MV
H'00000005 (5): PV/SP/Bank No.
PV/SP/soak time remain
H'00000006 (6): PV/SP/MV
PV/SP/soak time remain
H'00000007 (7): PV/SP/soak time remain
1002 3001 MV Display Selection H'00000000 (0): MV (heating)
H'00000001 (1): MV (cooling)
1006 3003 Automatic Display Return Time H'00000000 (0): OFF
H'00000001 to H'00000063 (1 to 99)
1008 3004 Display Refresh Period H'00000000 (0):OFF
H'00000001 (1): 0.25
H'00000002 (2): 0.5
H'00000003 (3): 1.0
1010 3008 Additional PV Display H'00000000 (0): OFF
H'00000001 (1): ON
1016 300B MV Display H'00000000 (0): OFF (display of manipulated variable OFF)
H'00000001 (1): ON (display of manipulated variable ON)
1018 300C Move to Protect Level Time H'00000001 to H'0000001E (1 to 30)
101A 300D PV Change Color H'00000000 (0): Orange
H'00000001 (1): Red
H'00000002 (2): Green
H'00000003 (3): Red to green: When ALM1 is ON
H'00000004 (4): Green to red: When ALM1 is ON
H'00000005 (5): Red to green to red: Within PV stable band: Green
Outside stable band: Red
H'00000006 (6): Green to orange to red: Within PV stable band: Orange
Outside stable band: Green, red
H'00000007 (7): Orange to green to red: Within PV stable band: Green
Outside stable band: Orange, red
101C 300E PV Stable Band Temperature: H'00000001 to H'00007E90 (0.1 to 3240.0)
Analog: H'00000001 to H'0000270F (0.01 to 99.99)
101E 300F Auto/Manual Select Addition H'00000000 (0): OFF
H'00000001 (1): ON
1020 3010 Character Select H'00000000 (0): OFF
H'00000001 (1): ON
